Watson-Marlow 313F - Manuel (Page 14)

79
313D, 314D, 313X and 314X
Références produits
Diamètre intérieur de tuyau flexible
mm " # Marprene Bioprene Peroxide Silicone Platinum Silicone
0.5 1/50 112 902.0005.016 903.0005.016 910.0005.016 913.0005.016
0.8 1/32 13 902.0008.016 903.0008.016 910.0008.016 913.0008.016
1.6 1/16 14 902.0016.016 903.0016.016 910.0016.016 913.0016.016
3.2 1/8 16 902.0032.016 903.0032.016 910.0032.016 913.0032.016
4.8 3/16 25 902.0048.016 903.0048.016 910.0048.016 913.0048.016
6.4 1/4 17 902.0064.016 903.0064.016 910.0064.016 913.0064.016
8.0 5/16 18 902.0080.016 903.0080.016 910.0080.016 913.0080.016
STA-PURE Tygon Viton Neoprene
0.8 1/32 13 920.0008.016
1.6 1/16 14 960.0016.016 950.0016.016 970.0016.016 920.0016.016
3.2 1/8 16 960.0032.016 950.0032.016 970.0032.016 920.0032.016
4.8 3/16 25 960.0048.016 950.0048.016 970.0048.016 920.0048.016
6.4 1/4 17 960.0064.016 950.0064.016 970.0064.016 920.0064.016
8.0 5/16 18 960.0080.016 950.0080.016 970.0080.016 920.0080.016
313D2, 314D2, 3132X and 3142X pumpheads
Références produits
Diamètre intérieur de tuyau flexible
Mm " # Marprene Peroxide Silicone Platinum Silicone STA-PURE
0.5 1/50 105 902.0005.024 910.0005.024 913.0005.024
0.8 1/32 108 902.0008.024 910.0008.024 913.0008.024
1.6 1/16 119 902.0016.024 910.0016.024 913.0016.024 960.0016.024
3.2 1/8 120 902.0032.024 910.0032.024 913.0032.024 960.0032.024
4.8 3/16 15 902.0048.024 910.0048.024 913.0048.024 960.0048.024
6.4 1/4 24 902.0064.024 910.0064.024 913.0064.024 960.0064.024
8.0 5/16 121 960.0080.024
Débits
