12
WIRING DIAGRAM
WH RD BK GY
BR
YL
BK RD
WH
YL
BR
WH
YL
RD
GY
YL/GN
YL/GN
BK
GY
Push b
utton s
witch
Switch Operation
Position Function
Off No connection
Lamps
Low speed
Med speed
High speed
GY/YL
(L - LA)
GY/WH
(L - 1)
GY/RD
(L - 2)
GY/BK
(L - 3)
YL
WH
BK BK
WH
BU
YL
BU
WH
BK
GY
Motor Specifications
Power Supply
Frequency
Power Absorption
120 VAC
60 Hz
240 WH
Motor Resistance (Ohms)
BU-RD
BU-GY
BU-BK
BU-WH
Room
temperature
37.7
30.3
28.8
45.1
73.4˚F (23˚C)
WH WH
WH
WH YL/GN
YL/GN YL/GN
SE13EB
M
V
1 5 2 3 4 6 7 8 9
3
2
1
L
La
M
12.5uF
