5
CONTROL PANEL AND FEATURES
Not all features and cycles are available on all models.
POWER
Touch to turn the dryer on and off. Touch to stop/cancel
a cycle at any time.
CYCLE CONTROL KNOB
Use your dryer’s cycle control knob to select available cycles
on your dryer. Turn the knob to select a cycle for your laundry
load. See “Cycle Guide” for detailed descriptions of cycles.
START/PAUSE
Touch and hold to start a cycle, or touch once while a cycle
is in process to pause it.
TIMED DRY ADJUST
Use “+” and “–” with Timed Cycles to increase or
decrease the length of a Timed Dry or Rapid Dry cycle.
LED DISPLAY AND SETTINGS
When you select a cycle, its default settings will light up and
the Estimated Time Remaining (for Sensor Cycles) or actual
time remaining (for Timed Cycles) will be displayed.
Touch the setting names next to the display to adjust settings.
See “Cycle Guide” for available settings on each cycle. Not all
settings are available with all cycles.
Temperature
When using Timed Cycles, you may select a dry
temperature based on the type of load you are drying.
Use the warmest setting safe for the garments in the load.
Follow garment label instructions.
NOTE: Sensor Cycles allow temperature adjustment. At
most, 3 of available temperatures (not including Air Only)
are allowed.
Dry Level
You may adjust the Dry Level on Sensor Cycles (except
for the Sanitize cycle), if desired.
NOTE: Dryness level is for use with Sensor Cycles only.
Wrinkle Prevent
If you will be unable to remove a load immediately, touch
Wrinkle Prevent to add up to 150 minutes of periodic
tumbling to help reduce wrinkling. On some cycles, you
may select the “With Steam” setting to add a short steam
cycle after 60 minutes to help smooth out wrinkles.
1
2
3
OPTIONS
Use to select available options for your dryer. Not all cycles
and options are available on all models.
Static Reduce (on some models)
Touch to add the Static Reduce option to selected Sensor
cycles (see “Cycle Guide”). The dryer will automatically
tumble, pause, and introduce a small amount of moisture
into the load to help reduce static. This option adds
approximately 8 minutes to the total cycle time.
Damp Dry Signal
Touch to select the Damp Dry Signal to Low, High, or Off.
When selected, a series of beeps will sound when the
load is damp, but not completely dry. This will allow you
to take clothes out of the load that do not need to
dry completely. This option is not available on Sanitize,
Steam Refresh, and the Timed Dry cycles.
Audio Level
Touch AUDIO LEVEL to change end beep and button
sounds simultaneously to Low, High, or Off.
CYCLE STATUS LIGHTS
The indicator bar on the right side of the control will let you
know what stage of the drying cycle is in process. For more
information on each stage, see “Cycle Status Indicators.”
Sensing
The Sensing indicator will light during Sensor Cycles
to indicate that the moisture sensor on the dryer is
operating. This indicator will not light during Timed
Cycles or options such as Wrinkle Prevent.
Steam
This indicator will light when a steam function is
active.
NOTE: Steam is not available on all models or
on all cycles.
Done
This will indicate that the selected cycle has ended
and the load may be removed from the dryer. If
Wrinkle Prevent has been selected, the dryer may
continue to tumble the load, even if the Done
indicator is lit.
Check Lint Screen
The Check Lint Screen indicator light will flash as a
reminder to clean the lint screen. It will flash until the
door is opened or a cycle is started. It will turn off
when the dryer is turned off.
4
NOTE: The control panel features a sensitive surface that responds to a light touch of your finger. To ensure your selections are registered,
touch the control panel with your finger tip, not your fingernail. When selecting a setting or option, simply touch its name.
3
2 1
5
5
6 7
4
5
6
7
