4
CONTROL PANEL AND FEATURES
Not all features and cycles are available on all models.
NOTE: The control panel features a sensitive surface that responds to a light touch of your finger. To ensure your selections are registered,
touch the control panel with your finger tip, not your fingernail. When selecting a setting or option, simply touch its name.
3
5
Model MHW7100D
Model MHW5400D
POWER/CANCEL
Touch to turn the washer on and off. Touch to stop/cancel
a cycle at any time.
NOTE: Turning the Wash Cycle knob will also turn the
washer on.
WASH CYCLE KNOB
Turn the knob to select a cycle for your laundry load.
An LED will light up for the cycle selected.
NOTE: The Clean Washer with affresh
® LED will flash when the
washer has run 30 wash cycles as a reminder to run the Clean
Washer with affresh ® cycle.
1
2
2
7
3
2
7
6
4
6
A
B
C
D
E
A
B
C
D
E
4
4
5
Model MHW4100D
3
2
7
4
6
D
C
A
E
5
See “Cycle Guide” for detailed descriptions of cycles.
NOTE: For best results when using the Overnight Wash & Dry
cycle, use for loads weighing 2.5 pounds and less, such as a
soccer uniform or a running tank and shorts.
START
Touch and hold until the light above START comes on to start a
cycle, or touch once while a cycle is in process to pause it. If you
want to add a garment, you can touch START when the “Add a
Garment” LED is on.
