Chapter 5 : LCD SCREEN DESCRIPTION (continued) TRIPLIX™ (TRC8022)
PAGE 24
5-5. LCD FUNCTIONS DESCRIPTION (continued)
10-6-2 [fade frame] + ENTER.
This function allows switching by a fading image (instead of a color). Then adjust the duration of the
transition.
10-6-3 [clean cut] + ENTER.
This function allows a clean switching thanks to a fast freeze of the displayed source.
10-7 [tally] + ENTER.
c First select a tally output with  + ENTER.
d Then select an input for this tally output with  + ENTER.
10-8 [key brightness] + ENTER.
Allows adjusting the key brightness.
10-9 [key locking] + ENTER.
Select an item with  and change the mode with ENTER.
• [menus]: Locks/unlocks the LCD CONTROL switches.
• [input]: Locks/unlocks the INPUT SELECTION and FREEZE switches.
• [all]: Locks/unlocks all the front panel switches.
NOTE: To unlock presses simultaneously on ENTER and EXIT.
• [autolock]: Allows selecting an input only if a signal is connected.
10-10 [erase all mem] + ENTER.
This function allows erasing all the NON-volatile image memories. Select [YES] and validate with ENTER.
10-11 [languages] + ENTER.
10-12 [demo mode] + ENTER.
This function allows playing a sequence of effect. Select [YES] and validate with ENTER.
10-13 [default value] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with
ENTER. Then switch OFF and ON the device.
FUNCTION POSITION FUNCTION POSITION
1 MODE mixer mode 6-1 USER 1 key Fading (2s).
2-1 input type computer HV/C 6-2 USER 2 key Title (holding).
2-2 used Inputs used 6-3 USER 3 key Shadow title (holding).
2-3 H Sync Load Hi-Z 6-4 USER 4 key H. WIPE: From left (2).
2-4 VCR mode OFF 7-1 master volume 191
3-1 output format 1024x768 7-2 audio mode stereo
3-2 output rate internal 60Hz 7-3 audio source auto follow
3-3 output sync H & V 7-4 audio level. 48
3-4 type of screen 4/3 7-5 audio balance. 32
3-5 test pattern no pattern 8-1 master volume 191
4-2-1 horizontal position 128 8-2 audio mode stereo
4-2-2 vertical position 128 8-3 audio source auto follow
4-2-3 horizontal size 128 8-4 audio level. 48
4-2-4 vertical size 128 8-5 audio balance. 32
4-3 aspect ratio 4/3 10-5 2:2 pull down auto
4-4 brightness (video) 128 10-6 transition fade color
4-4 black level (computer) 128 10-9 key locking all off
4-5 contrast (video) 128 10-12 demo mode no
4-5 color (computer) R = 128, G = 128, B= 128
4-6 color (video) 128
4-6-1 clock (computer) 0
4-6-2 phase (computer) 0
4-7 hue 128
4-8 u/overscan overscan
4-9 sharpness 0
