Samsung HW-S800B 330W 3.1.2-Channel Soundbar System (Black) - Manuel (Page 10)

ENG - 10
6
Info
Press the button to display information about the current function. (See page 7)
When connected to Dolby Atmos®, the LED indicator blinks cyan 3 times.
7
SOUND MODE
By pressing the button, you can select the desired audio mode. Each time the mode changes, the Multicolor LED
blinks in white.
LED indicator
White Blinks X1
“ Surround ” → “ Game ” → “ Standard ” → “ Adaptive Sound ” →
“ DTS Virtual:X ”
• Surround
Provides a wider sound field than standard.
• Game
Provides stereoscopic sound to immerse you in the action while gaming.
• Standard
Outputs the original sound.
• Adaptive Sound
Analyzes the content in real time and automatically provides the optimal sound field based on the
characteristics of the content.
• DTS Virtual:X
Immersive 3D sound from any content.
8
VOLUME
Push the button up or down to adjust the volume.
LED indicator
White moves to right X1
Volume Up
White moves to left X1
Volume Down
9
WOOFER (BASS)
LEVEL
Push the button up or down to adjust the level of the woofer (bass) to -12 or between -6 to +6. To set the woofer
(bass) volume level to 0 (Default), press the button.
10
Bluetooth PAIR
Switch the Soundbar to Bluetooth pairing mode.
When you press the button, the LED display changes as shown below.
• Until pairing is complete, the Multicolor LED changes as
Red → Green → Blue in turn.
LED indicator
Red → Green →
Blue Blinks
Pairing
Cyan Blinks X3
Connection is complete
“ Ready to connect via Bluetooth. ”
11
CH LEVEL
By pressing the button, you can adjust the volume of the each speaker.
• To control the volume of the each speaker select “
Center Level ” or “ Front Top Level ” in Sound Settings, and
then adjust the volume between -6~+6 by using the Up / Down buttons.
• If the Rear Speakers (sold separately) are connected, the setting “ Rear Level ” and “ Rear Top Level ” is
supported. To adjust the volume of the “ Rear Level ” and “ Rear Top Level ” between -6 to +6 by using the Up /
Down buttons.
LED indicator
White Blinks X1
“ Center Level ” → “ Front Top Level ”
