The photograph above, with the lower
basket removed, shows the main points
described in this Instruction Book.
1 - Work top
2 - Upper basket
3 - Cleaning liquid container
4 - Regenerating salt container
5 - Self-cleaning micro filter
6 - Rating plate (After sales service
references)
7 - Lower sprinkling arm
8 - Main filterl
9 - Waste
trap
10 - Rinsing product container
