GB
7 6
GB
Loading the dishwasher
Upper basket (Fig. 11 - 12)
This basket is particularly intended to hold
glasses, cups, ramekins, small salad bowls,
bowls, saucers etc…
Place glasses so that they do not touch and tip
them sufficiently so that they do not retain any
water. Place the hollow end of glasses, cups
and bowls facing downwards. Arrange the
dishes methodologically to gain space (rows of
glass, cups, and bowls)
Use the height adjustable holding bar for large
glasses or large-stemmed glasses.
Cups, ladles, etc... can be arranged too on the
rack.
The upper basket should be adjusted to the
HIGH position when loading large plates in the
lower basket. The setting can be execute
basket in charge.
Setting the HIGH POSITION
Slowly lift the basket until you hear a
click on each side.
Setting the LOW POSITION
Lift the basket completely on both sides
(click) and then follow it downwards.
Make sure that the two runners are
adjusted to the same level.
① ①
② ②
Adding the rinse aid
Rinsing product is necessary as it avoids stains
on the dishes and makes drying easier.
IMPORTANT! Only use products intended
for dishes and NOT detergents intended for
hand washing !
Filling and adjusting the rinsing
product container (Fig. 6 - 7)
Put the door in a horizontal position when filling
the container and unscrew the cap in the door
clockwise.
Fill to just below the to the adjusting lever.
If the product overflows during filling, remove
the excess with a sponge to avoid foam
forming.
If you experience stains or bad drying after
several cycles, you may if necessary adjust the
dosage using the selector:
Soft water : level 1 to reduce the dose
Hard water : level 3 to increase it.
Finding the level of the rinsing
product.
A light on the control band shows you
requirements in rinsing product when the door
is ajar.
In order to obtain good cleaning results, be
sure to remove any large food residues before
switching on the machine. Any burnt or stuck-
on residues must be removed beforehand.
The dish-washer has two racks for 12 place-
settings, or 140 items (figures 10-11-13), to
standard DIN 44990. Always point the inside of
the crockery downwards. Ensure that no item
conceals another and that nothing obstructs
the spraying facility. After switching on, check
that the spraying arms can move freely. No
item should overlap the baskets.
Lower basket (Fig. 8 - 9 - 10)
Place the dishes so that water may circulate
freely and spray all the utensils. (Avoid
attaching and piling dishes up).
This basket is especially intended to hold:
plates, cutlery, dishes, frying pans, saucepans.
Put large-sized plates and frying pans on
the side.
Avoid mixing plates and soup dishes. You
should preferably place same-sized plates
together. Place soup dishes at the back, in
the high pin area.
Make sure nothing obstructs the rotation of
the lifting arm (saucepan handles, cutlery or
large dishes).
The baskets in the bottom rack fold away
(fig. 9B) to take large dishes.
The cutlery trays slide and can be put
anywhere on the lower basket. You can adjust
them according to the dishes you wash.
Removable grids are available if you wish to
load cutlery in an orderly fashion.
For optimum washing, you can use these
separation grids.
Cutlery : (Fig. 13 - 13B)
• Place handles downwards.
• Separate silverware from other metals using
the separating grill.
• It is preferable to place small spoons in the
separating grills.
IMPORTANT NOTE : For reasons of
safety, we recommend you place sharp-
ended table knives blade down in the
cutlery basket.
Long-bladed cutlery and other sharp
utensils should be placed flat in the upper
basket.
Adding the detergent
The washing product container has been
placed in front of the upper basket to make the
machine easier to fill. This means that you can
load the washing powder without bending down
or completely opening the door.
tablet
Use washing products specifically designed
for dishwashers. See the manufacturers’
recommendations on the packet as well as the
advice for use below.
The distributor offers you a choice between using tablets or powder
or liquid detergent.
Before starting the programme :
put the tablet in the upper compartment.
Put the tablet in the outside compartment. Using tablets is
particularly recommended for the WASH 55°C programme and for
full loads of dishes.
Or,
Pull the container to fill with washing powder or liquid and fill
up to:
Minimum setting for slightly dirty dishes
Maximum setting for dirty dishes
Close the container
VERY IMPORTANT: keep all products out of the reach of
children and away from humidity.
powder or liquid
