GB
11 10
GB
Technical characteristics
Option : building the free-standing machine in
Voltage : 230V - Fusibles : 10 A
Power : 2150 W
Capacity : 12 place settings
Water pressure 1-10 bar
Water evacuation pipe height : 60-100 cm. Your
dishwasher complies with the following European
Directives 73/23/CEE (low voltage directive),
89/336/CEE (electromagnetic compatibility)
modified by the directive 93/68/CEE.
Built-in option
If you want to build the machine in under an
existing work-top, you will have to fix the
front frame to a solid work-top. To do this:
-Remove the top panel by unscrewing the two
screws located under the edge of the top
panel.
- Slide the machine into place.
- Adjust the heights of the feet is necessary
(Fig. 4).
- Fix your dishwasher to the kitchen worktop by
two screws under the front frame.
If your dishwasher is underneath a work
surface with a hob, you must add thermal
insulation to the top of the machine. You can
obtain this thermal insulation kit from your
dealer.
Operation
- Open the door and load the dishwasher.
Make sure the crockery does not obstruct the
rotating arms.
- Pour washing powder into the distributor.
- Close the door.
Selecting a programme
First, turn on power to the dishwasher (Start
key), then select your programme by pressing
the key. Each time you press, the indicators go
on and off in the order from “Delicate wash”
to “Soak”. They do so in the reverse order if
you press the key .
The indicator light that is on shows you the
programme you have selected. The duration of
the programme you have chosen appears on the
display if you have not selected a delayed start.
The programme selected remains memorised
after a power failure, or after pressing the
“Start/Stop” key.
Selection of the condensor drying
option
In order to improve the drying of the various
dishes , your machine is equipped with a drying
condensor.
Select this option by pressing on the key "
condensor ", the appropriate led will light on.
This process make you able to get a perfect
drying of your dishes, without steam at the
opening of the door. This option remains
memorised at the end of the cycle.
If you want to cancel it, just press the key a
second time, the led will light off.
To select “Delayed start”
Once you have selected your programme, press
the “Delayed start” key. The indicator will then
show a delay time of one hour. Each time you
press on the key, the time is increased by one
hour to a maximum of 9 hours.
Should you press the key yet again (over and
above the 9 hours), you will see displayed the
duration of the programme (immediate start).
Then the display will count down the time til the
start of the programmme.
To start the programme
After choosing your programme (with or without
option), press the “Programme start” key .
The “Delayed start” indicator light goes on if a
delayed start has been selected. Otherwise,
the “Soak” indicator light goes on.
Running of a programme
The programme starts. The display shows the
approximate duration of the cycle, in minutes,
til the end of the programme.
The "O.C.S. system " leds light on during the
three first minutes. Then the leds "Cleaning,
Rinse, Drying " light on one after the other
according to the running of the programme.
End of a programme
The programme is over when the led "stop" is
lighted on. The display shows "00" til the
opening of the door.
After the opening of the door, the display will
show again the duration of the programme
previously selected.
To cancel a programme while it is
running
Hold the “Start” button down for three seconds.
the led "stop” lights on, the display shows “00”
until a new programme is selected.
The missing product indicator
lights
goes on when the machine is turned
on.
salt : Lights up when salt is low. After you
have added regenerating salt it may stay on
until the salt has dissolved sufficiently. This
happens generally after a cycle (or if you have
not properly filled the machine – see page 5)
for example when starting off with the sample.
Note : Where water is particularly soft
regenerating salt is not needed but the light will
remain on.
rinsing product : Goes on, door ajar,
when you should add rinsing product (see
filling page 6).
