10
Preparation before washing
Before washing, please do take out coins,
keys and other hard goods, and zip up clothes
and barrel from damage.
！
NOTICE
Adjust the adjustable foot to make
the washer be placed stable. 1
Adjustable foot (extend when
clockwise rotating and shorten
when counterclockwise rotating)
(Slightly incline the washer first and loosen the
adjustable foot knob. Adjust the adjustable foot so
as to ensure four corners of washer be steadily
contacted with the ground. Then tighten the
adjustable foot knob and lock it. If the ground is
obviously not flat, correction should be made on
the ground surface, otherwise the washer barrel
will incline and knock the cabinet)
Connect with to
power source. 3
4
+ +
Put down the drain
hose.
5
Upper drain
Note:
The water
will overflow
when the
height of
the drain
hose under
860mm. >
860mm
Put in
clothes
and
suitable
amount of
washing
powder. 6
Install the water
inlet hose. 2
For two inlet hoses
+ + + +
tightly to prevent them
Turn on the
water supply.
When installing the quick sink faucet adapter to the faucet, follow the steps below:
1.First,remove the aerator from your faucet nozzle and determine the size/type of
the faucet.
2.Once you determine the size/type of the faucet(Outside Threaded End or Inside
Threaded End),place the proper sized rubber washer into the silver faucet adapter.
3.Attach the silver faucet connector to the faucet.
4.Attach the faucet connector to the water inlet hose and make sure that the rubber
washer is placed in between.
5.Attach the other end of the water inlet hose to the washer water inlet and make
sure that the rubber washer is placed in between.
Washers
Faucet
Faucet Adapter
Quick Connector
Washer
Water inlet hose
Drain hose
Washer
Rear View of Washer
Installing Quick Sink Adapter
9
