The washing machine can self determine and send buzzing alarming to some errors and
incorrect operation. The causation of the error will show on the LED display . In this
case, please check the points hereinafter. Plug out and contact with the local service
center for their help if the washing machine can not self rectify after all the following
points have been checked. Do not repair by yourself, which is dangerous.
Symptom
The machine
does not work
The electricity is off
The power plug is not plugged tight.
The power switch is not switched on
Turn the electricity on
Re-plug the power plug.
Check the power socket, or
change other
inlet was stopped up by the sundries.
Whether the washing machine leak
Power off, wait for coming water.
Open the lid and tap, close the lid
Open the lid, dislodge the sundries,
close the lid.
Power off, plug out, send to repair
Alarming for
opening lid
Having opened the lid before spin
Open the lid after preset
Cover the top lid
Cover the top lid
Unbalance alarming
The laundry is uneven. Open the top lid, replace the
laundry evenly, and close the top lid.
Does not drain
The drain hose is twisted or
jammed or placed too high.
Open the lid, solve the problem
of jam, and close the lid
Overflow alarming
Water level is higher than rated
overflow level Power off, repair
Causation Solution
No water supply
The tap is not open
Flashing.
(Water inlet
error)
1.There is water injection during washing or rinse. That is because the washer senses a lack of water
and changes water level automatically.
2.There is the phenomenon of intermittent spinning in the beginning of spinning, which is performed
to achieve better spinning effects.
3. In the course of spin, the program returns to the rinse program .This is designed to rectify unbal-
anced distribution of load in the tub.
The following cases are not faults
Door-lock failure
Not normally open or unlocked
door
the door can be open only by pull
up the power when the door is
locked, and it can power-off and
alarm-cleared by press the power
key when the door lock is open.
No
washing
Abnormal
draining
Abnormal
spin
Identify usual trouble of washer
List of faults and inspection
Faults Inspection Items
No water
flows in
! If the power is off or the fuse is burned out.
! If the water supply is cut off or the water pressure is too low.
! If the inlet hose is properly connected and the water tap is opened.
! If the filtering screen of inlet valve is blocked by dirt.
! If the coil of inlet valve is damaged. (The slight electromagnetic
sound is normal phenomenon when the inlet valve is switched on)
! If the "Start / Pause" button is pressed after the power
switch is pressed.
! If the door lid is closed.
! If all clothing piled largely at one side of barrel or the clothing
is excessively placed.
! If the washer is not placed in stable condition or it is placed in
inclination state. (The ground is not flat).
! If the motor belt is loosened.
Note: During the spin process, if washing are piled at one side of the spin barrel,
it will cause unbalance of spin barrel resulting in striking. At this moment, the
computer inside the washer will feel this unbalance phenomenon and will automatically
correct it ( fill in water Washing ). However, if unbalance situation is not removed after
continuous three corrections, which means the computer auto-correction can not
resolve the problem. Then the user has to manually and evenly place the clothing
inside the barrel to solve the problem.
When the washer is in trouble, please contact local service office or the sales service
department of our company and the customer should not dismantle the machine without
permission.
If the washer can not work normally, or appear abnormity or alarms, please check and
correct as follows.
! If the water drain hose is placed very high.
! If the end of water drain hose is sealed in pond.
! If the internal rubber ring of drain valve is blocked by dirt.
! If the power is off or the fuse is burned out.
! If the power supply voltage is too low.
! If the water amount reaches to the required water level.
(The washer will not work if the water amount does not reach the
required water level)
! If it is set to "Delay" washing mode. (It will only start to work
until the reservation time reached)
Malfunction display and solutions
