Curtis FRF707 - Manuel (Page 9)

8
4. Electrical connection
• This appliance should be properly grounded for your safety. The power cord of this
appliance is equipped with a three-prong plug which mates with standard three-prong
wall outlets to minimize the possibility of electrical shock.
• Do not under any circumstances cut or remove the third ground prong from the power
cord supplied.
• Plug the appliance into an exclusive, properly installed, grounded wall outlet. Any
questions regarding power and/or grounding should be directed toward a certified
electrician or an authorized Summit service center.
• It is recommended that a separate circuit serving only this appliance be provided. Use
a receptacle that cannot be turned off with a switch or pull chain.
• The use of extension cords is strongly discouraged.
• This appliance requires a standard 115/120-volt, 60 Hz electrical outlet with three-prong
ground and a 15-amp fuse. To prevent accidental injury, the power cord should be
secured behind the appliance and not left exposed or dangling.
NOTE: Before performing any type of installation, cleaning or removing a light bulb, turn the
thermostat control to OFF and then disconnect the unit from the electrical power source.
When you are finished, reconnect the refrigerator to the power source and reset the
temperature control to the desired setting.
Operation
1. Before the freezer is plugged in, check the following:
-There must not be any damage on all electrical wire.
-Earthing screw must be well fixed.
-Wall outlet must be properly earthed.
Be sure that everything is in normal condition and the freezer can be plugged in.
2. When operating for the first time
When operating is in normal condition and the freezer without any load until it auto stops at the
desired temperature, usually it takes 2 or 3 hours. Then set the thermostat to the required
setting and place foods in.
3. Temperature control
The temperature in the freezer is controlled by the Thermostat. Freezer's temperature can be
adjusted by turning the knob of the thermostat. “0” switches the unit off and “3” is the coldest
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the
power cord is damaged, have it replaced by an authorized service technician.
