Distribution des plots et câbles de raccordement pour les interfaces
de données
18.2
18
TNC 620 | Manuel utilisateur Programmation en DIN/ISO | 3/2015
579
Prise femelle RJ45 pour Interface Ethernet
Longueur de câble max. :
non blindé : 100 m
blindé : 400 m
Broche
Signal
Description
1
TX+
Transmit Data
2
TX–
Transmit Data
3
REC+
Receive Data
4
libre
5
libre
6
REC–
Receive Data
7
libre
8
libre
