Z-Wave Remote Control
Include or exclude the Dimming Switch Module from the existing
Z-Wave home control network with your primary controller.
-
Refer to your primary controller instructions to process the
inclusion / exclusion setup procedure.
- When prompted by your primary controller, tap the button.
- The primary controller should indicate that the action was
successful. If the controller indicates the action was
unsuccessful, please repeat the procedure.
- Once the Dimming Switch Module is part of the network, the
same basic procedure is used to add the Dimming Switch
Module to groups or scenes. Refer to the primary controller's
instructions for details.
All On/All Off functions
Depending upon your primary controller, the Dimming Switch
Module can be set to respond to ALL ON and ALL OFF
commands up to four different ways. Some controllers may not
be able to change the response from its default setting. Please
refer to your controller's instructions for information on whether or
not it supports the configuration function and if so, how to change
this settings.
The four possible responses are:
-
It will respond to ALL ON and the ALL OFF commands
(default).
- It will not respond to ALL ON and ALL OFF commands.
- It will respond to the ALL OFF command but will not respond
to the ALL ON command.
- It will respond to the ALL ON command but will not respond to
the ALL OFF command.
Restoring Factory Defaults
All Configuration Parameters can be restored to their factory
default settings by using your primary controller to reset the
device. (delete from the network)
8 9
WARRANTY
Dimming Switch Module warrants the product to be free from
manufacturing defects for a period of one year from the original date
of consumer purchase. This warranty is limited to the repair or
replacement of the product only and does not extend to
consequential or incidental damage to other products that may be
used with this product.
This warranty is instead of all other warranties, expressed or implied.
Some states do not allow limitations on how long an implied warranty
lasts or permit the exclusion or limitation of incidental or
consequential damage, so the above limitations may not apply to you.
This warranty gives you specific rights, and you may also have other
rights which vary from state to state. Please contact Customer
Service at:
Zwave Products,
111 roosevelt Ave Westwood NJ 07675
email: [email protected]
www.zwaveproducts.com
7
Certifications
UL Listed:
This power unit is intended to be correctly orientated in a vertical
or floor mount position.
FCC Information
FCC ID : ZGID9190A01
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
-
Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
IC information
IC : 9548A-D9190A01
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the
device.
This device complies with RSS-310 of Industry Canada.
Operation is subject to the condition that this device does not
cause harmful interference.
There is no user serviceable parts in the
Dimming Switch Module.
To avoid the risk of electric shock, the input prong comes with a
round grounding plug. The switch module can only be plugged in to
the power inlet with the grounding plug. Please contact a qualified
electrician to replace the power inlet if it has no grounding inlet. Do
not change the plug of Dimming switch model in any way.
RISK OF FIRE
RISK OF ELECTRICAL SHOCK
RISK OF BURNS
DID NOT QUALIFY FOR INSTRUMENT OF MEDICAL AND LIFE
SUPPORT EQUIPMENT
Z-Wave Dimming Switch Module never got qualified certificate to
supply power for medical instrument or any life support equipment.
This Dimming Switch Module is complied with the Z-Wave standard
of open site, line of sight transmission distances of up to 25m. Actual
RF performance of Dimming Switch Module in a home was affected
by the number of barrier/construction between the remote controller
and the destination unit, in meanwhile, relies on the number of Z-
Wave enabled devices installed in the control network.
F820-8010-0000
TECHNICAL SPECIFICATIONS
Specifications subject to change without notice due to continuing product improvement
Rating input:
Double outlets:
Max. power of "Always On"
pass through outlet:
120Vac
up to 25m (line of sight between the Wireless
Controller and the closest Z-Wave receiver
module.)
Z-Wave controllable
"Always On" pass through
DIMMER(Dimming/ON/OFF) or
SWITCH(ON/OFF) mode
SWITCH:
a. Max Incandescent Load 330W 2.75A
b. Max Resistive Load 500W 4.16A
DIMMER:
Max Incandescent load 330W 2.75A
Max. range:
Resistive load 1200W
Input frequency: 60Hz
RF frequency: 908.42MHz (ZDS-100US)
Max. output power of
Z-Wave controlled:
Selectable switch:
Resistive load 1400W Max. power in total for both
Z-Wave Outlet and Always
on Pass through outlet:
DIMMER:
Can only be connected to incandescent lamp,
Resistive load.
SWITCH:
Can be connected to incandescent lamp,
Resistive load.
Connect ability:
Detected internal temperature, and cut off
output once OTP triggered.
(Remark: Under over loading or temperature
situation, it will fail to start up).
Meet FCC15 Class C and RSS 210 issue 8.
Meet standard UL244A edition third revision
th 2010-3-4 and CSA C22.2 No.14 11 with
revision date 2010-2-1 and UL1310 fifth date
2005-05-03.
Over Temperature protection:
EMC:
Safety:
126X68X40mm
180g
o -10~60 C
o 0~40 C
5~95%
Indoor use only
Dimension (L x W x H):
Weight:
Storage:
Operation Temperature:
Relative Humidity:
Environment:
