Radson Minuterie - Manuel (Page 3)

3
If you wish to limit the room temperature to a
predefined level:
• Remove the temperature knob.
Find the temperature indicators [see diagram
opposite] and place the pins there.
• Place the knob back on the thermostat.
REPLaCiNG EMiTTER BaTTERiES
Batteries must be replaced when the receiver does
not register orders sent by the emitter [low batteries]
or when the light [5] doesn’t react to operations
carried out on the emitter [flat batteries].
• Replace the batteries with 2 new flat CR2430 type
batteries.
SPECifiC RECOMMENdaTiONS
When using, you may notice that the upper and lower
parts of the appliance are not as hot as the rest of it:
• The upper parts are not completely full to allow
for the heat-conductor liquid to expand when the
device is switched on.
• The lower parts carry the liquid on its return cycle
after it has transmitted its heat.
SPECifiC CaSE Of REGuLaTiNG
uSiNG ThE PiLOT wiRE [BLaCK wiRE]
Your appliance enables you to manage orders sent
by EDF [cf. Tempo rates]. It also enables you to view
them using display [A] or [F] [depending on how the
device is equipped]:
1. Comfort: constant green light.
2. Reduced: flashing green light
[3,5°C below set temperature].
3. Freeze protection mode: light is off with green
flashes [set temperature=7°C].
4. Off: Light is off.
5. Comfort -1°C: green light with single blink.
6. Comfort -2°C: green light with double blink.
Orders generated by the user.
Orders generated by EDF.
MaiNTENaNCE
Use a soft, dry cloth to clean the control box.
Never use abrasive cleaning products.
TEChNiCaL SPECifiCaTiONS
Margin for measuring
temperature
0.1°C [receiver]
Margin for setting the
temperature
0.5°C
Range of temperature 5°C -30°C
Electrical protection Receiver: Class II - IP44
Power [receiver] 12A / 250V RELAIS 16A
Batteries [emitter]
2 flat CR2430 type
batteries provided [with
an approximately 24
month life]
