LauNChiNG a MaNuaL BOOST
This function enables you to increase the tempera-
ture in your room rapidly and/or to dry your towels
for 2 hours. The device’s thermostat will not be in use
over this period.
The device will function normally again [the thermo-
stat will be used to regulate room temperature] as
soon as the timer stops.
• Press the OK/Boost button: when it is released, the
light [5] will flash once to show that the manual
Boost has been registered, and the receiver light [1]
will flash red.
NOTE:
You can stop the Boost at any time by pressing the
button again. The receiver light [1] will stop flashing.
PROGRaMMiNG daiLY BOOSTS
The infrared room thermostat enables you to
programme 2 daily Boosts P1 and P2.
Programming a daily P1 Boost
• Turn the cursor [8] to P1.
• At the desired time, press the OK/Boost button for
three seconds to save the P1 cycle:
- The light [5] will flash twice briefly to indicate
that the daily Boost has been registered, and the
receiver light [1] will flash red.
- The Boost will start immediately for 2 hours and
will repeat after 23 hours and 15 minutes, and
then every 24 hours.
Example: The first morning at 7 o’clock, press the OK/
Boost button for three seconds. The next day, and on
subsequent days, the appliance will switch on at 6.15
for 2 hours. At the end of the Boost, the device goes
back to comfort mode.
Programming a second daily P2 Boost
• Turn the cursor [8] to P1+P2.
• Proceed as for programming P1 Boost .
- The second 2 hour Boost will start immediately
and will repeat after 13 hours and 15 minutes,
and then every 24 hours.
NOTE: You can stop the timer at an time by pressing
the OK/Boost button briefly.
Changing a programmed Boost
• Turn the cursor [8] to the chosen programme and,
at the desired time, press the OK/Boost button
for 3 seconds: the new cycle will be saved and the
previous one will be erased.
NOTE: 2 quick flashes indicate that a P1 Boost [or
P2 Boost] programme has already been saved when
going into P1 mode [or P1+P2 mode].
RETuRNiNG TO faCTORY SETTiNGS
This will erase all programmes and restore the default
factory settings.
• Turn the cursor [8] to mode then press down for
at least 10 seconds:
- The light [5] will flash twice to indicate that the
re-set has been registered.
- P1 and P2 programmes will be erased.
CaLiBRaTiNG ThE ThERMOSTaT
It is normal for there to
be a 1 to 2°C difference
between the temperature
displayed on the emitter
and that measured by a
thermometer.
If you wish to synchronize
these two values, let your
thermostat regulate the
temperature for at least
an hour and then proceed
as follows:
Example: you have set
your
thermostat to
21°C. After an hour of
regulating the tempera-
ture, the thermometer is
displaying 23°C.
• Remove the temperature knob, taking care not to
turn it at the same time.
• Remove the knob’s central notched axle [with a
small pair of pincers] and put the axle back in the
thermostat pivot, without making it move round.
• Then place the knob back so as the temperature
you have measured is the same as that shown on
the thermostat dial.
SETTiNG a MaXiMuM TEMPERaTuRE
fOR ThE ThERMOSTaT
