9
Looped power cord
1. Firmly grasp the yellow shipping strap and pull until both ends are completely removed
from washer.
2. Check that two (2) shipping pins were removed with the shipping strap.
Connect Drain Hose
Proper connection of the drain hose protects your floors from damage due to water leakage.
Read and follow these instructions.
The drain hose is connected to your washer and is stored inside the washer cabinet.
Remove drain hose from washer cabinet
Gently pull the corrugated drain hose out of the washer from the top of the hose. Continue to
pull the hose until the end emerges. Do not force excess drain hose back into the rear of the
washer.
Laundry tub drain or standpipe drain
Connecting the drain hose form to the corrugated drain hose
1. Feed end of drain hose into one end of form. Place end of drain hose form into the drain
hose relief.
2. Bend the hose over the top of the form and feed into the other end of the form.
To keep drain water from going back into the washer:
■ Do not force excess drain hose into standpipe. Hose should be secure but loose enough
to provide a gap for air.
■ Do not lay excess hose on the bottom of the laundry tub.
Looped power cord
A. Drain hose reliefs
A
