Exclusive Data
3.1 MMC Commands
No. Description Value Notes
1 Exclusive F0H
2 Universal Real Time 7FH
3 Device ID 0-7FH
4 MMC command 06H
5 Command Number 01-0DH * see table right
6 EOX F7H
* Sending by [RECORDER CONTROL] buttons
* Transmit only
MMC Commands
01 STOP 08 RECORD PAUSE
02 PLAY 09 PAUSE
03 DEFERRED PLAY 0A EJECT
04 FAST FORWARD 0B CHASE
05 REWIND 0C COMMAND ERROR RESET
06 RECORD STROBE 0D MMC RESET
07 RECORD EXIT
3.2 Parameter Send
No. Description Value Notes
1 Exclusive F0H
2 KAWAI ID 40H
3 Channel no. 0nH n=0-FH
4 Function no. 10H Parameter Send
5 Group no. 00H MI Group ID
6 Machine no. 12H MP11 Machine ID
7 data1 40H Setup Parameter
8 data2 0-7fH Address MSB
9 data3 0-7fH Address LSB
10 data4 0-7fH data size (byte) max=128 byte
11 data5~ data max 128byte
12 EOX F7H
3.3 Setup Address: Global Section
Category Parameter Address MSB/LSB (HEX) Byte Value (HEX)
SETUP Setup Mode On/Off 00/49 1 00,01 (Off , On)
SETUP Bank / Variation 00/19 2 Bank=00-19 (A~Z), Vari=00~07 (1~8)
GLOBAL Global EQ Switch 00/1B 1 00,01(Off , On)
Global EQ Low Gain 00/1C 1 36-40-4A (-10~+0~+10 dB)
Global EQ High Gain 00/1D 1 36-40-4A (-10~+0~+10 dB)
Global EQ Mid1 Gain 00/1E 1 36-40-4A (-10~+0~+10 dB)
Global EQ Mid2 Gain 00/1F 1 36-40-4A (-10~+0~+10 dB)
Global EQ Mid1 Q 00/20 1 00-06 (0.5~4.0)
Global EQ Mid2 Q 00/22 1 00-06 (0.5~4.0)
Global EQ Mid1 Frequency 00/21 1 00-7F (200~3150Hz)
Global EQ Mid2 Frequency 00/23 1 00-7F (200~3150Hz)
Transpose Switch 00/3D 1 00,01 (Off ,On)
Transpose Value 00/3E 1 28-40-58 (-24~0~+24)
