Service
Page 8-3
1
13
08014
PULLEY ASSEMBLY - 4.50
2
2
08135
BRG,
BALL
3
4
08229
P/PIN,DETENT
4
2
11040-301
CLAMP BLOCK INSERT
5
4
11040-440
KNOB
6
2
3900-438
DECAL,
CYBEX
7
2
4605-323
WT ROD .625 DIA x 45.00
8
2
4700-019
BEARING,
FLANGE
.62 ID. x .92 OD. x 1.50 LG
9
1
4800-255
C TOP WT 15-4 X 18
10
1
51073
HIP
HARNESS
11
1
51122
ANKLE
STRAP
12
1
51198
WARRANTY BOOKLET (NOT SHOWN)
13
1
54001
SIGN FACILITY SAFETY
14
1
54600
FT360 TRAINING CD ROM
15
1
9100-006
PALLET,
SHIPPING
16
2
9100-204
P ARM ADJUSTMENT
17
2
9100-303
MOLDED PULLEY SWIVEL
18
2
9100-304
DECAL, ROTATIONAL POSITION 1 - 10 0
19
1
9100-311
CAP, SHROUD COVER
20
1
9100-313
DECAL, WEIGHT PLATE 1 - 25
21
2
9100-314
CYLINDER,
DAMPNER
22
4
9100-315
CLIP, DAMPNER SAFETY
23
2
12220-005
HANDLE
ASSEMBLY
24
2
9100-318
GRIP, 5.88 LG x 2.00 OD x 11 GA WALL
25
2
9100-343
PLATE, SPRING CABLE RETAINER
26
4
9100-353
SPACER, ARM CLEVIS
27
1
9100-365
PANEL, SHROUD FRONT
28
1
9100-367
PANEL, SHROUD END RIGHT SIDE
29
1
9100-368
PANEL, SHROUD END LEFT SIDE
30
4
9100-380
DECAL ABC POSITION
31
4
9100-381
PULLEY PIVOT PIN
32
4
9100-383
BUSHING
33
1
9100-384
PANEL, SHROUD BACK
34
1
9100-385
HINGE, .06 x 2.00 x 62.00 LONG
35
1
9101-002
CABLE
S/A
36
2
9101-003
CABLE
S/A
37
1
9101-200
W MAIN FRAME
38
1
9101-203
P/ BELT CLAMP POST
39
1
9101-204
P/BELT
CLAMP
ITEM
QTY
PART NO.
DESCRIPTION
9101 - FT-360S Station
40
2
9101-300
SPRING, EXTENSION 1.671 x 1.995 x 26.00
LG
41
1
9101-60
FT-360S COATED ASSY
42
2
AH020000
SWIVEL
HOUSING
43
1
BH030207
PIN, WEIGHT SELECTOR
44
2
BR030206
RING,
RETAINING
45
4
BR030213
RETAINING RING, 2.00 EXTERNAL
46
4
BR030214
RETAINING RING, .625 DIA
47
2
BR030224
RETAINING RING, 1.188 INTERNAL
48
4
BS070201
COM SPRING .56 x .66 1.50 LG
49
1
CC010203
BOX, RSC 10 X 6 X 12 (NOT SHOWN)
50
1
CJ000027
BUBBLE WRAP, 24 INCHES WIDE
51
1
CM000211
DECAL, PATENT PENDING
52
1
CP300200
BAG, POLY 4.00 x 4.00
53
1
CP300201
POLY BAG 9 X 12
54
2
EW000027
CABLE
TIE
55
2
FB030213
ROD END BEARING FEMALE .375-24 UNF
56
4
FB130206
BEARING, FLANGE 2.00 ID. x 2.25 OD. x 1.00
LG
57
4
FB130212
BUSHING, FLANGE .75 ID x .875 OD x .75 LG
58
66.375”
GB000202
BELT, .95 WIDE
59
2
GP000000
PULLEY ASSEMBLY - 4.50
60
2
GP000209
PULLEY
ASSEMBLY-3.50
61
2
GQ000206
SNAP
LINK
62
4
HC700415
BHSCS .375-16 X .75
63
4
HC700426
BHSCS .375-16 X 2.00
64
2
HC700428
BHSCS .375-16 X 2.25
65
4
HC702815
SHCS .375-16 X .750
66
2
HC702817
SHCS .375-16 X 1.00
67
4
HC702822
SHCS .375-16 X 1.50
68
46
HF579000
PANEL FASTNER, 10-24 U TYPE
69
4
HF700000
PANEL FASTNER, .375-16 , U TYPE
70
4
HM580410
BHSCS .190 10-32 X .375
71
4
HN-60065
NUT, HEX SELF- LOCKING .312-18 BLK ZINC
72
6
HN704400
NUT, HEX JAM .375-16
73
24
HN704901
LOCKNUT, .375-16 NYLON
74
2
HP286715
PIN, .188 DIA x .75 ROLL
ITEM QTY
PART
NO.
DESCRIPTION
Cybex FT-360S Functional Trainer Owner’s Manual
