8 — English
TO CHARGE
See Figure 2, page 11.
When charging the screwdriver, a red charge light will
illuminate on the handle of the screwdriver. This red charge
light will go off when the screwdriver is fully charged.

Insert charger plug into input jack making sure it is
properly connected.
 Charger can be used with normal household current of
120 V, AC only, 60 Hz.
 Connect charger to power supply.
 After normal usage, a minimum of 9 hours of charging
time is required to fully recharge the screwdriver.
 Do not place charger in an area of extreme heat or cold.
It will work best at normal room temperature.
 Remove the product from the charger once it is fully
charged and ready for use.
wARNING:
Battery products are always in operating condition.
Therefore, the switch should always be locked when not
in use or carrying at your side.
ADJUSTABLE TORQUE CLUTCH
This screwdriver is equipped with an adjustable torque clutch
for driving different types of screws into different materials.
The proper setting depends on the type of material and the
size of screw you are using.
ASSEMBLy
UNPACkING
This product has been shipped completely assembled.

Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
 Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
 Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
 If any parts are damaged or missing, please call
1-800-525-2579 for assistance.
PACkING LIST
Screwdriver
Bit Set
Tool Bag
Charger
Operator’s Manual
wARNING:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
wARNING:
Do not attempt to modify this product or create acces-
sories not recommended for use with this product. Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
wARNING:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
product when assembling parts.
OPERATION
wARNING:
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a second
is sufficient to inflict serious injury.
wARNING:
Always wear safety goggles or safety glasses with side
shields when operating products. Failure to do so could
result in objects being thrown into your eyes, resulting in
possible serious injury.
wARNING:
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
APPLICATIONS
You may use this product for the purposes listed below:

Driving screws with screwdriver bits
 Light-duty drilling
