7 — English
SyMBOLS
SERVICE
Servicing requires extreme care and knowledge and should
be performed only by a qualified service technician. For
service we suggest you return the product to the nearest
AUTHORIZED SERVICE CENTER for repair. When
servicing, use only identical replacement parts.
wARNING:
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in the
operator’s manual, do not use this product. Call Ryobi
customer service for assistance.
wARNING:
SAVE THESE INSTRUCTIONS
The operation of any power tool can result in foreign objects being thrown into your eyes, which can
result in severe eye damage. Before beginning power tool operation, always wear safety goggles or
safety glasses with side shields and, when needed, a full face shield. We recommend Wide Vision
Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI Z87.1.
FEATURES
PRODUCT SPECIFICATIONS
Motor ........................................................................4 V DC
Switch ...........................................Single Speed/Reversible
No Load Speed ........................................ 180 r/min. (RPM)
Clutch .............................................................. 12 Positions Torque ..................................................................... 45 in. lb
Collet ........................................SPEEDLOAD +™ SYSTEM
Charger Input.....................................120 V, AC only, 60 Hz
Charge Rate .......................................................9-12 hours
kNOw yOUR SCREwDRIVER
See Figure 1, page 11.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
DIRECTION OF ROTATION SELECTOR
(FORwARD/REVERSE/CENTER LOCk)
Your screwdriver has a direction of rotation (forward/
reverse/center lock) selector located above the switch trigger
for changing the direction of bit rotation. Setting the switch
trigger in the
OFF (center lock) position helps reduce the
possibility of accidental starting when not in use.
LED wORkLIGHT
The screwdriver has a built-in LED worklight that illumi-
nates when the switch trigger is depressed. This feature is
convenient when working in close or tight areas where
additional light is needed.
SPEEDLOAD+™ SySTEM
Your screwdriver has the SPEEDLOAD +™ SYSTEM, the
fastest and most convenient way to change any 1/4 in. hex
shank bits.
TORQUE ADJUSTMENT RING
Your screwdriver has a 12-position clutch. The torque
adjustment ring can be turned to select the right amount of
torque for the application.
