2
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools before starting installation. Read and follow the
instructions provided with any tools listed here.
ALL INSTALLATIONS
Tools Needed:
•
Tape Measure
•
Straightedge
•
Pencil
•
Phillips Screwdriver
•
Level
•
Wire Cutters and Wire Stripper
•
Hand or Sabre Saw
•
1” Hole Saw
•
Drill and Drill Bit
•
Safety Gloves and Goggles
•
Volt Meter (0-250VAC)
TECHNICAL DATA
OVEN DIMENSION MODEL
Electrical Ratings and Maximum
Connected Load
SINGLE OVEN
multifunction 24" (60 cm)
HCW225LAES
HCW225RAES
HCW2360AES
@ 240 Volts
60 Hz
@ 208 Volts
60 Hz
Amperes Watts Amperes Watts
13.3 3100 11.7 2350
LOCATION REQUIREMENTS
IMPORTANT: Observe all governing codes and ordinances.
•
Cabinet opening dimensions that are shown must be used. Given dimensions
provide minimum clearance with oven.
•
Recessed installation area must provide complete enclosure around the
recessed portion of the oven.
•
The oven support surface must be a minimum ¾” (2 cm) thick plywood platform.
The platform must support 100 lbs (45 kg), and be solid, level and flush with the
bottom of the cabinet cutout.
•
Grounded electrical supply is required. See “Electrical Requirements” section.
•
Electrical supply junction box should be located 3” (7.6 cm) maximum below
the support surface when the oven is installed in a wall cabinet. A 1” (2.5 cm)
minimum diameter hole should have been drilled in the right rear or left rear
corner of the support surface to pass the appliance cable through to the junction
box.
NOTE: For undercounter installation, it is recommended that the junction box be
located in the adjacent right or left cabinet. If you are installing the junction box
on rear wall behind oven, it is recommended that the junction box be recessed
and located in the upper center of the cabinet.
