8
49-80835 Rev. 5
USING THE COOKT
O
P:
Power Sharing / Cooktop Lockout / Single Kitchen
T
imer
Power Sharing
Cooktop Lockout
Single Kitchen Timer
A 36” cooktop has 3 cooking zones and a 30” cooktop
has 2 cooking zones. If two elements in the same zone
are in use and at least one element is at the maximum
power level (Hi), the Hi setting will operate at a reduced power level. Note that the display will not change. This is
how power is shared between two elements in the same
cooking zone.
Lock
Touch Control Lock pad for 3 seconds.
Unlock
Touch Control Lock pad again for 3 seconds.
See Custom Settings section to activate Auto Lock feature.
To Turn On
Touch the Timer pad. Touch the ೸ or V arrows
to choose the desired number of minutes. Timer
automatically starts 3 seconds after pad is touched. The
“ON” LED will appear automatically when timer is set.
To Turn Off
Hold Timer pad for 3 seconds to cancel timer. Alarm
will sound continuously when time is up until user turns
timer off.
NOTE: Use the kitchen timer to measure cooking time
or as a reminder. The kitchen timer does not control the
cooking elements. Timer turns off if there is no activity
for 30 seconds.
30” Wide cooktop. 36” Wide cooktop.
Left Zone Right Zone Center Zone Left Zone Right Zone
Cooktop Lockout: locks operation of the controls
Control Lock
Indicator/Symbol
