Cafe 30 Inch Induction Cooktop Owner Manual - Manuel (Page 10)

49-80835 Rev. 5
9
USING THE COOKT
O
P:
Cooktop Communication Module Setup / Wi-Fi Commissioning
Wi-Fi Commissioning
Cooktop Communication Module Setup (If Applicable)
Turning On the Wi-Fi
Download the SmartHQ App onto your mobile device and create an account. Use the + button on the SmartHQ App
homepage to add the cooktop, follow the steps in the SmartHQ App to connect Wi-Fi.
Press and hold the Precision Cooking button for 3 seconds until display reads “Add”. Tap the twice until the
display reads “Off”. Tap the to turn Wi-Fi On. The will start blinking. The will turn solid when complete
steps in the SmartHQ App. To exit Commissioning and Pairing, press Precision Cooking button one time, or menu
will automatically exit after 60 seconds of no user input.
Look at the underside of the cooktop in the front/left
corner to see if there is an input connector jack.
If the connector jack looks like this then no further action
is required, proceed to Wi-Fi Commissioning.
If the connector jack looks like this then refer to the
instruction insert included in the literature packet
titled “Important Installation Instruction Cooktop
Communication Module” for setting up this device.
Turning Off the Wi-Fi
Hold the Precision Cooking pad for 3 seconds until display reads “Add” and Bluetooth symbol is blinking. Tap
twice until the display reads “On” and the and the is blinking. Tap to turn Wi-Fi Off. The icon will turn off
when complete.
