9 - Final checklist
To prevent improper connections leading to damage of
electrical components and so voiding the warranty, the
following steps must be performed:
1. Check the electrical requirements and make sure you have
the correct electrical supply and that the range is properly
grounded.
2. Before the range is connected, turn on the power supply.
3. Check power at the junction box wires using a voltmeter
having a range of 0-250 VAC. If you have installed the
oven for use on 240 Volt supply, you should find that the
voltage reading between the black and red wires (Line to
Line) should be 220 to 240 Volts. If you have modified the
range(s) for use on 208 Volt, the voltage reading between
the black and red wires should be 190 to 208 Volts.
4 Connect the range to the power supply.
5. Set the clock by following these steps:
• Press TIME key twice until the display shows “SET TIME”.
• Immediately press + or - keys to set hours.
• Press TIME key again to change minutes.
• Immediately press + or - keys to set minutes, hold to
change by ten (10) minutes step.
• Press TIME key or wait for a few seconds.
Clock is now set.
6. Test the bake mode by following this step:
• Move cooking mode knob to “BAKE” position.
• Cooling fan, oven lights, preheat led will turn on.
• A beep is sounded when the oven reaches the preset
350 °F (175 °C) and the preheat light turn off.
• Move the knob back to “OFF” position to stop cooking.
7. To check the other oven functions refer to the “Using the
Oven Controls” section of the USE AND CARE MANUAL.
8. If the oven is working properly, turn off the power supply to
the oven.
9. Place the cover on the junction box and make sure the cover
is securely fastened and turn on the power to the oven.
IMPORTANT
Leave these INSTALLATION instructions as well as the USE
AND CARE MANUAL with the owner.
CONNECTING TO 208 VOLT CIRCUIT
This option is provided for areas where standard 240 Volt
service is not available. This option must be accessed with the
appliance connected to power source, and using the following
sequence:
1. Within five minutes from power up, hold MENU and TIME
keys for 3 seconds to enter the user option menu. The
display shows as follows:
2. Hold then TIME and LIGHT keys until the display becomes
dark.
3. Hold MENU and LIGHT further, until the time display shows
“Volt” and temperature module shows “240” blinking,
waiting for an input.
4. Using + or - keys, the control toggles between 240V
and 208V options. Hold MENU to confirm.
5. Hold TIME and LIGHT keys in order to quit the selection.
6. Hold MENU key for 3 seconds to quit the user option menu.
The voltage setting is stored and kept even after a long
power-off.
