28
Pressure Regulator
Replace Injector On (Oven Lower Burner)
1) Remove the burner cover plate.
2) Remove the screws A securing the oven burner and withdraw the burner from the support.
3) Remove the injector by turning 9-32” nut driver counter clockwise.
4) Install the injectors supplied with this appliances in the appropriate burner. The injectors have small number stamped
on the side, this number codes the orifice diameter and its correct burner location (see figure of the paragraph “Injectors
position”).
5) Turn clockwise to tighten (tighten to a torque of 15 to 20 inch-lbs);
6) Replace all parts following the reverse order. Save the injectors removed from the appliances for future use.
