49-5000760 Rev. 0
11
INST
ALLA
TION INSTRUCTIONS
Installation Instructions
For more help, visit GEAppliances.com
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•
IMPORTANT –
Save these
instructions for local inspector’s use.
•
IMPORTANT –
Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time ±$SSUR[LPDWHO\KRXU
• We recommend that two people install this
product.
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
‡ <RX0867XVHSURSHULQVWDOODWLRQSURFHGXUHVDV
described in these instructions when installing this
air conditioner.
Power cord includes a current interrupter device. A
TEST and RESET button are provided on the plug
case. The device should be tested on a periodic
basis by first pressing the
TEST button and then the
RESET button while plugged into the outlet. If the
TEST button does not trip or if the RESET button
will not stay engaged, discontinue use of the air
conditioner and contact a qualified service technician.
ELECTRICAL REQUIREMENTS
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
Do not change the plug on the power cord of this
air conditioner.
Aluminum house wiring may present special
problems—consult a qualified electrician.
For Existing Wall Sleeves
)RU([LVWLQJ:DOO6OHHYHV
1RWHWKDWWKHDLUFRQGLWLRQHUGLPHQVLRQVDUH
Width-26”
Height-15 ¾”
Depth-18 ¼” (without front cover)
Depth-16” (rear of chassis to rear edge of front grille)
Install air conditioner according to these instructions
to achieve the best performance. Installing this air
FRQGLWLRQHULQH[LVWLQJVOHHYHVWKDWGRQRWDOORZIRU
proper fit or have proper outdoor grilles may affect
performance and could void the manufacturer’s
warranty.
Parts Included
• Security bracket and screws for a 26” wall sleeve (2)
• Remote Control (1)
IMPORTANT NOTE
For optimal energy efficiency and performance, we
recommend using the RAB26A or the RAB46B wall
sleeves with the RAG13A rear grille.
CAUTION
