LIGHTING
7
PORTA-CHEF 320 PORTA-CHEF 100 PORTA-CHEF 120
A. BURNER CONTROL D. HANDLE
B. IGNITOR E. CYLINDER VALVE
C. MANUAL LIGHTING HOLE F. REGULATOR
LIGHTING INSTRUCTIONS
1. The appliance must be assembled as per the
assembly instructions.
2. Ensure LP cylinder is full and properly connected to
the regulator. See: “Hose and Regulator.” (Page 4)
3. Ensure there are no gas leaks in the gas supply
system. See: “Leak Testing.” (Page 5)
4. Ensure that the venturi tubes are properly located
over the gas valve orifices. See “Venturi Tubes.”
(Page 6)
5. Ensure that ignition wires are connected.
6. Carefully review all instructions on the information
plate attached to the gas grill.
7. WARNING: Always open lid before lighting and
do not lean over gas grill while lighting.
8. Set control knobs to “OFF” and turn on the gas supply.
LIGHTING THE BURNER:
a. Open gas grill lid and leave open until lit.
b. Check that the battery has been installed in the
electronic ignition.
c. Push and turn one main burner control knob to
“HIGH.”
d. Push and hold down the ignitor button or use match
to light.
e. Burner should ignite within 5 seconds; turn off gas
source immediately if ignition does not occur in this
timeframe. To light burner with a match proceed
below to step f.
f. Insert lit match through lighting hole located at the left
or right side of the cook box.
g. Push and turn right main burner control knob to
“HIGH.”
h. Burner should ignite within 5 seconds.
i. After the first burner is lit, push and turn the adjacent
main burner control knob to “HIGH” then repeat for
other burners; these burners should light
automatically without the ignitor.
CAUTION - Check your gas grill after lighting .
All burner ports should show a 2.5cm / 1” flame on “HIGH.”
If any of the following symptoms occur there is probably a
blockage in the venturi tubes. Shut off gas at once and
clean the venturi tubes. See “Venturi Tubes.” (page 5)
1. You smell gas.
2. A flashback fire occurs.
3. Your gas grill heats unevenly.
4. The burners make popping noises.
IF BURNER DOES NOT IGNITE:
1. Push and turn control knob to “OFF.” Wait 5 minutes
then try again with control knob set at “MEDIUM.”
2. If any burner will not light, see “Troubleshooting” (page
10). If problem persists, do not attempt to operate the
appliance; contact OMC, your dealer or an approved
service center.
SHUTDOWN:
1. Turn off cylinder valve.
2. Turn control knobs to “OFF.”
