8
en-us Before you begin
Before you begin
Before you begin Tools and parts needed
▯
Torx head screwdriver
▯
1/8" drill bit and drill
▯
Measuring tape
Parts included
▯
Microwave oven
▯
3 Torx screws
Power Requirements
This appliance requires connection to a dedicated 208/
240V branch protected supply fitted with a suitably
approved 20A circuit breaker. It must be properly
grounded in accordance with all applicable codes. The
product is supplied with 1.8 m of flying cables in a
flexible conduit which are factory fitted. The colors of the
conductors are:
▯
L1: Red
▯
L2: Black
▯
N: White
▯
E: Green/Yellow
Planning notes
Door hinge not interchangeable.
Distance from furniture body to door front 1 7 /
8
” (47 mm).
Distance from furniture body to outer edge of door
handle 3¾” (94 mm) after retrofitting the handle (special
accessory).
Pay attention to the front protrusion, possibly including
the door handle, for opening drawers at the sides.
When planning a corner solution, pay attention to the
door opening angle of at least 90°.
Preparing Kitchen Units
Preparing Kitchen Units Kitchen units must be temperature-resistant up to
195° F (90 °C) and adjoining furniture frontages up to
160° F (75 °C).
Cut recesses on the furniture before inserting the
appliance. Remove any shavings, as these can affect the
operation of electrical components.
Refer to the installation drawings on the following pages.
Secure unsecured furniture items to the wall using a
commercially available bracket.
Only install the appliance so high that accessories can
be removed with ease.
