Asus ROG GT-AX11000 Tri-Band Wi-Fi Gaming Router - Manuel (Page 100)

100
4.6.3 3G/4G
3G/4G USB modems can be connected to the router to allow
Internet access.
NOTE: For a list of verified USB modems, please visit:
http://event.asus.com/2009/networks/3gsupport/
To set up 3G/4G internet access:
1. From the navigation panel, click Advanced Settings > USB
application > 3G/4G .
2. In the Enable USB Modem field, select Yes .
3. Set up the following:
• Location: Select your 3G/4G service provider’s location from
the dropdown list.
• ISP : Select your Internet Service Provider (ISP) from the
dropdown list.
• APN (Access Point Name) service (optional) : Contact your
3G/4G service provider for detailed information.
• Dial Number and PIN code : The 3G/4G provider’s access
number and PIN code for connection.
NOTE: PIN code may vary from different providers.
• Username / Password: The username and password will be
provided by the 3G/4G network carrier.
• USB Adapter : Choose your USB 3G / 4G adapter from the
dropdown list. If you are not sure of your USB adapter’s
model or the model is not listed in the options, select Auto .
4. Click Apply .
NOTE: The router will reboot for the settings to take effect.
