Yorkville Sound SA153 Synergy Array Series 15" 3-Way Powered Portable PA Speaker - Manuel (Page 5)

3
Specifications
Active or Passive Active
Program Power (watts) 2600 program (5000 peak)
Biampable Triamp
Measured Max SPL (C-Weighted, Max Hold) 131dB Continuous 137dB Peak
Frequency Response (Hz +/- 3db) 55-18K
Dispersion (°H x °V) 22.5x45 asymetrical 10 up, 35 down
Crossover Frequency (Hz) 400, 7k
Cabinet Configuration Patented Synergy Horn and Paraline Lens Technology
Driver Configuration 1x15-inch LF woofer, 1x MF/HF Co-ax Compression Driver
HF Driver 1.75-inch Diaphragm/Voice Coil Annular Co-axial
HF Program Power (watts) 300
HF Impedance (ohms) 16
HF Protection Peak and Average Limiting
MF Driver 3.5-inch diaphragm/voice coil annular coaxial
MF Program Power (watts) 300
MF Impedance (ohms) 16
MF Protection Peak and Average Limiting
LF Driver 1x15-inch neodymium woofer with 3.5-inch voice coil
LF Program Power(watts) 2000 program (4000 peak)
LF Impedance (ohms) 8
LF Protection Excursion, RMS
HF Power Amplifier (watts) 300
HF Amplifier Type 3-Tier Class H
MF Power Amplifier (watts) 300
MF Amplifier Typ 3-Tier Class H
LF Power Amplifier (watts) 2000
LF Amplifier Type Class D
Cooling Scheme Convection
Power Cable Removable Locking Powercon True Input and Loop Thru Output
Power Switch Yes
Power Consumption (typ/max) 220 VA / 400 VA
Inputs 1 XLR, 2 x XLR Loop
Input Sensitivity (Vrms Sine) Line in 1.4 at center, 0.56 at max
Level Controls Volume
EQ Controls HF/MF Boost select, Fullrange/Sub switch
LED Indicators Power, Limit, Clip
Enclosure Materials Multiply 15mm Birch Plywood
Standard Rigging Hardware RAIL and LOCKBAR Rigging System (Top and Bottom)
Stacking Feature Interlocking UHMW Feet (top and bottom)
Covering / Finish Paint
Dimensions (DWH xbackW, inches) 24 x 21 x 26.5 x 12.25
Dimensions (DWH xbackW, cm) 60.9 x 53.3 x 67.3 x 31.1
Weight (lbs/kg) 115/52.1
* Specifications subject to change without notice
