8 9 Quick Start Guide DN9630
Installation
Before installing and operating this equipment, make sure it is correctly connected to the
protective earth conductor of the mains voltage supply.
Ideally a cool area is preferred, away from power distribution equipment or other potential
sources of interference.
Do not install the equipment in places of poor ventilation.
Do not install this equipment in a location subjected to excessive heat, dust or mechanical
vibration. Allow for adequate ventilation around the equipment. Whenever possible, keep the
equipment out of direct sunlight.
Minimum Hardware:
Windows-based application
• • Core 2 Duo CPU, 2 GHz
• • Ethernet port
• • 1 GB RAM
Mac
• • 1.5 GHz CPU
• • Ethernet port
• • 512 MB RAM
Recommended Operating Systems:
Windows
• • Windows 7, 32-bit or 64-bit
• • Windows 8, 32-bit or 64-bit
Mac • • 10.8 Mountain Lion
Power
The DN9630 is powered via USB from a computer USB connection.
Make sure the plug fi tted on the supplied USB cable is securely fi tted to the USB port on the unit.
When fi tting or removing a plug, always hold the plug itself and never use the cable, as this may
damage it. Never insert or remove an electric plug with wet hands.
Handling the equipment
When lifting or moving the equipment, always take its size and weight into consideration.
Completely isolate the equipment electrically and disconnect all cables from the equipment
before moving it.
Driver Installation (Windows)
1. Download the latest DN9630 Windows driver from the Klark Teknik website
2. Unzip the downloaded fi le
3. Connect the DN9630 to your PC via USB
4. Run the setup.exe fi le and follow the on screen instructions
Electric fi elds
In accordance with Part 15 of the FCC Rules & Regulations, “… changes or
modifi cations not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.”
Should this product be used in an electromagnetic fi eld that is amplitude modulated by an audio
frequency signal (20 Hz to 20 kHz), the signal to noise ratio may be degraded. Degradation of
up to 60 dB at a frequency corresponding to the modulation signal may be experienced under
extreme conditions (3 V/m, 90% modulation).
Connecting up
The DN9630 unit uses the following leads and connectors:
Digital Connections:
AES50 - Neutrik etherCON
USB - USB 2.0, B-type
Power Connection:
USB 2.0, B-type
