6 7 Quick Start Guide DN9630
1. Introduction
Welcome!
Thank you for purchasing the DN9630 AES50 to USB 2.0 Converter!
The DN9630 provides a multichannel interface between AES50 networks and your computer.
Once the DN9630 is connected to a computer it will appear as a normal soundcard on your
Mac or PC.
Features
• • AES50 to USB 2.0 converter for simultaneous computer audio recording and playback
• • Up to 48 bidirectional channels @ 48 kHz and 24 bidirectional channels @ 96 kHz
• • Switchable 48 kHz and 96 kHz sample rate operation
• • Operates from incoming AES50 clock
• • Powered via USB 2.0 interface
• • Native Core Audio* driver support in Mac OS X*, software drivers available for Windows* PC
• • LED indicators monitor network activity and speed
• • Compact and rugged design with durable aluminium extrusion casing
• • 10-Year Warranty Program*
• • Designed and engineered in the U.K.
*Mac and OS X are trademarks of Apple Inc. Windows is either a registered trademark or trademark of Microsoft Corporation in the United
States and/or other countries.
About this manual
This is the operation manual for the DN9630 AES50 to USB 2.0 Converter. This manual is intended
to help get your unit installed and in operation as quickly as possible by giving you unpacking,
installation, connection, setting up and operating instructions. To help familiarise you with
the DN9630, there is a description of the front and rear panels, along with easy-to-follow
user instructions.
2. Getting Started
This section shows you how to unpack, install, connect up, switch on and confi gure the DN9630
AES50 to USB 2.0 Converter.
Unpacking
Carefully unpack your DN9630 unit. Then, inspect the DN9630 unit carefully for any signs of
damage that may have occurred during transit, and then notify the courier immediately if you do
discover any damage.
Check the contents of your DN9630 unit equipment package. If there are any parts missing,
incorrect or faulty, please contact your local distributor or KLARK TEKNIK at the address at the
front of this manual.
Please retain the original packing in case you should need to return the equipment to the
manufacturer or supplier, or transport or ship the unit later.
Before installing, setting up or operating this equipment, make sure you
have read and fully understand all of the “IMPORTANT SAFETY INSTRUCTIONS”
at the front of this document.
