ENG - 8
Rear Panel of the Soundbar
DC 19V
SERVICE
HDMI (ARC) DC 19V
SERVICE
HDMI
(ARC)
DC 19V
SERVICE
HDMI (ARC) DC 19V
SERVICE
HDMI
(ARC)
DC 19V
SERVICE
HDMI (ARC) DC 19V
SERVICE
HDMI
(ARC)
3
1
2
1 SERVICE
Connect a USB storage device to upgrade the product’s software.
2 HDMI (ARC)
Connect to the HDMI (ARC) port on a TV. (See page 17)
3 DC 19V
Connect the AC/DC power adapter. (Power Supply In) (See page 14)
• When disconnecting the power cable of the AC/DC power adaptor from a wall outlet, pull the plug.
Do not pull the cable.
• Do not connect this unit or other components to an AC outlet until all connections between components are complete.
