Samsung HW-S800B 330W 3.1.2-Channel Soundbar System (Black) - Manuel (Page 34)

ENG - 34
15 SPECIFICATIONS AND GUIDE
Specifications
Model Name HW-S800B / HW-S801B
Weight 3.1 lbs (1.4 kg)
Dimensions (W x H x D)
45.7 x 1.5 x1.6 inches
(1160.0 x 38.0 x 39.9 mm)
Operating Temperature Range +41°F to +95°F (+5°C to +35°C)
Operating Humidity Range 10 % ~ 75 %
AMPLIFIER
Rated Output power
(20W x 2) + (10W x 2) + (20W x 2) + (10W x 1) + (10W x 2)
Supported play formats
Dolby 5.1ch / Dolby Digital Plus / Dolby ATMOS (Dolby Digital Plus) /
DTS 5.1ch / LPCM 2ch
Subwoofer Name
HW-S800B : PS-WB85D
HW-S801B : PS-WB86D
Weight 14.1 lbs (6.4 kg)
Dimensions (W x H x D)
9.4 x 9.5 x 9.4 inches
(238.0 x 240.8 x 238.0 mm)
AMPLIFIER
Rated Output power
200 W
NOTE
• Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
• Weight and dimensions are approximate.
Precaution : The Soundbar will restart automatically if you turn on/turn off Wi-Fi.
To deactivate Wi-Fi connection:
Press and hold the CH LEVEL button on the remote control of the Soundbar for more
than 30 seconds to turn on or off the Wi-Fi connection.
To deactivate Bluetooth connection:
Press and hold the TONE CONTROL button on the remote control of the Soundbar for
more than 30 seconds to turn on or off the Bluetooth connection.
