Roborock S7 MaxV Ultra FCC - Manuel (Page 9)

10
Notes:
• If the power cable hangs vertically to the ground, it may
be caught by the robot, causing the dock to be moved or
disconnected.
• The dock indicator is on when the dock is powered on, and
off when the robot is charging.
• The dock indicator turns red if an error occurs.
• Place the dock on a flat floor away from fire, heat, and
water. Avoid narrow spaces or locations where the robot
may be suspended in the air.
• Placing the dock on a soft surface (carpet/mat) may cause
the dock to tilt over and cause problems docking and
departing.
• Keep the dock away from direct sunlight or anything that
may block the dock location beacon; otherwise, the robot
may fail to return to the dock.
• Do not use the dock without clean water tank, dirty water
tank, high-speed maintenance brush, dustbin, dust bag or
water filter.
• Maintain the dock according to the maintenance
instructions. Do not clean the dock with a wet cloth or
tissue.
• All docks are subject to water-based tests before leaving the
factory. It is normal that a small amount of water remains in
the waterway of the dock.
Option 2: Search for “Mi Home” in the App
Store or Google Play or scan the QR code to
download and install the app.
Connecting to the App
Option 1: Search for “Roborock” in the App
Store or Google Play or scan the QR code to
download and install the app.
❶ Download App
This robot supports both Roborock and Mi
Home apps. Choose the one that best
meets your needs.
Note: The robot may not be turned on when the battery
is low. In this case, connect the robot to the dock.
B1-5— more than 0.5 m (1.6 ft)
B1-6— more than 1.5 m (4.9 ft)
B1-7— more than 1 m (3.3 ft)
B2
Power on and charge the
robot
Place the dock on a hard and flat floor
(wood/tile/concrete etc.), flat against a
wall. Keep at least 0.5 m (1.6 ft) of
clearance on either side, 1.5 m (4.9 ft)
in front, and 1 m (3.3 ft) above. Make
sure the location has good WiFi for a
better experience with the mobile
app, and then turn it on.
Press and hold the button to power
on the robot. Wait until the power light is
steady, and then place the robot on the
dock to charge. The robot is equipped
with a high-performance lithium-ion
rechargeable battery pack. To maintain
battery performance, keep the robot
charged during normal use.
B1-4—
Slide the bracket forwards under the water
tank. A click indicates that it is locked in
place.
B3-2—Install the mop bracket
Insert the VibraRise mop cloth into the
bottom along the attachment slot and stick
it firmly in place.
B3-1—Install the VibraRise mop cloth
Note: To prevent excessive dirt buildup during first-time
use, floors should be vacuumed at least three times before
mopping.
B3
Mopping
B3-3—
WARNING
Risk of injury. Do not place your finger
between VibraRise mop bracket and water
tank.
