Roborock S7 MaxV Ultra FCC - Manuel (Page 12)

13
• Firmware Update
• Video Call
• Volume Adjustment
• Language Selection
• Do Not Disturb Mode
• Voice Assistant Support
Restore Factory Settings
If the robot does not function properly after
a system reset, switch it on. Press and hold
the button and at the same time press
Reset button until you hear the “Restoring
factory settings” voice prompt. The robot
will then be restored to factory settings.
System Reset
If the robot does not respond when a
button is pressed or cannot be turned off,
reset the system. Press the Reset button,
and the robot will reset automatically.
Note: After resetting the system, scheduled cleaning, WiFi,
etc. will be restored to factory settings.
App Features
Note:
Note:
Functions and details of the app may vary slightly due
to the continuous app development and updates.
Only available in the Roborock app.
Cleaning Map
Custom Cleaning Modes
Cleaning Mode Switch
Robot Information
More Features
• Multi-map management
• Real-time vacuum and mop route
• Carpet display
• Map zoning
• Map editing
• Scheduled
• Selective Room
• Zone
• No-Go Zones, No-Mop Zones, and
Invisible Wall
• Custom
• Carpet Boost
• Suction Power Levels
• Mop Intensity Levels
• Cleaning History
• Battery Level
• Care & Maintenance
C1
Main Brush
C2
Side Brush
* Clean every 2 weeks and replace every 6-12 months.
C1-1— Main Brush Cover
C1-2—Latches
C1-3—
Main Brush
C1-4— Main Brush Caps
C1-5— Main Brush Bearing
C1-6— Turn over the robot and press the
latches to remove the main brush cover.
Pull out the main brush and remove
the main brush bearing.
Rotate the main brush caps in the
indicated unlock direction to remove
the caps.
After removing the tangled hair or
dirt at both ends of the main brush,
reinstall it, press on the main brush
cover to lock it in place.
C1-8—
C1-9—
Notes:
• Main brush should be wiped down with wet cloth and left
to dry away from direct sunlight.
• Do not use corrosive cleaning fluids or disinfectants to
clean the main brush.
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
* Clean monthly and replace every 3-6 months.
C1-7—
Routine
Maintenance
C
