Medal Sports 44113 Manuel d'utilisation
Page 3
Advertising
2
Inner Leg
x 2
Outer Leg
x 2
Table Tennis Top - D
x 1
Table Tennis Top - C
x 1
1
Table Tennis Top - A
x 1
2
9
17
18
10
11
12
13
14
15
16
3
4
5
6
7
8
Castor
x 4
Outer Leg Cap
x 4
Net Post
x 2
Inner Leg Cap
x 4
Table Tennis Top - B
x 1
Metal Frame
x 2
End Apron
x 2
Long Side Apron
x 3
Corner Cap
x 4
Linkage Tube With Stop Bracket
x 2
Linkage Tube
x 2
Table Tennis Ball
x 3
Table Tennis Net
x 1
23
24
19
20
21
22
Table Tennis Paddle
x 2
Gravity Lock
x 2
6 X 50mm Bolt
x 8
6 X 42mm Bolt
x 10
6 X 13.5mm Bushing
x 8
T - Washer
x 2
Nut
x 8
25
26
5 X 12mm Screw
x 131
Pre-installed
Pre-installed
Short Side Apron
x 1
27
Locking Nut
x 2
29
30
28
Metal Plate
x 6
Washer
x 28
Slotted Leg Bracket
x 8
31
32
Leg Bracket
x 4
33
35
36
34
Allen Key
x 2
WM44113 CAN PARTS LIST
Control Box
x1
Electronic Scorer
x 1
Connecting Wire
x 1
