6. Attach the Leg to the Main Cabinet (#1) using four Bolts (#15) and four Washers (#16) per Leg. See FIG.2.
7. Attach the Lower Side Apron (#8) to the Leg using four Bolts (#13) and four Washers (#14) per Apron. See FIG.3.
8. Attach the Lower End Apron (#9) to the Leg using four Bolts (#13) and four Washers (#14) per Apron. See FIG.3
and 3A.
Go back and make sure that all connections are tight.
