39603 PARTS LIST
Main Cabinet
1 Piece
Lower Side Apron
2 Pieces
Lower End Apron
2 Pieces
Leg Cabinet - C
4 Pieces
Leg Cabinet - D
4 Pieces
Leg Cabinet - A
4 Pieces
Leg Cabinet - B
4 Pieces
Top Leg Base
4 Pieces
Bottom Leg Base
4 Pieces
6 x 45mm Bolt
16 Pieces
8mm Washer
16 Pieces
6mm Washer
32 Pieces
Corner Pocket
4 Pieces
Side Pocket
2 Pieces
4 x 37mm
Flat Head Screw
16 Pieces
4mm Allen Key
1 Piece
Name Plate
1 Piece
Pre-installed
Pre-installed Pre-installed Pre-installed
Pre-installed
Pre-installed
Triangle
1 Piece
6 x 24mm Bolt
16 Pieces
8 x 55mm Bolt
16 Pieces
57” Cue
2 Pieces
Chalk
2 Pieces
2-1/4” Billiard Ball
1 Set
Wooden Brush
1 Piece
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
16 17 18 19 20
21
26
22 23 24 25
Shim
9 Pieces
27 28
6mm T - Nut
16 Pieces
8mm T - Nut
16 Pieces
6mm Nut
16 Pieces
Pre-installed
29
EVA Pad
4 Pieces
