LOCATION OF CONTROLS
PLAY / PAUSE
BUTTON
BAND SELECTOR FUNCTION SELECTOR
DAIL POINTER
SKIP UP BUTTON
SKIP DOWN BUTTON
REPEAT BUTTON
LED DISPLAY
VOLUME CONTROL
CD TRAY
STOP BUTTON
PROG BUTTON
TUNING KNOB
CD TRAY
OPEN / CLOSE
BUTTON
POWER BUTTON
POWER INDICATOR
FM ST. INDICATOR
HEAD PHONE JACK
TUNER
1) Turn the unit “ON” using the POWER
This function is used to play audio from your portable/external audio device on this unit.
- Connect a RCA cable to the Aux-In jack on this unit and the output jack on your device.
- Switch the function selector to AUX.
- Press play on your device and enjoy.
Knob.
2) Select the desired band using
FUNCTION Knob.
3) Tune in the desired station using the
TUNING Knob. If the FM ST. band was
chosen, the FM STEREO indicator will
light up whenever a stereo broadcast
is received. To listen in Mono or to im-
prove noisy, weak-signal stereo broad-
cast, select FM Mono band using the
BAND FUNCTION switch. The STEREO
indicator will go off and FM Mono
will be received.
PHONO
TO PLAY VIA AUX-IN
5) Place the tone arm on the desired position. 1) Set the FUNCTION Knob to the PHONO.
2) Set the speed selector to the proper position
depending on the record to be played.
3) Place the record on the platter (if required,
use the 33/45/78 rpm adaptor)
4) Lift the tone arm from the rest and slowly
move it to the record side. The platter will
begin to rotate.
6) Adjust VOLUME controls to the desired
sound level.
7) To stop manually, lift the tone arm from the
record, and return it to the rest.
4) Adjust the VOLUME controls to the desired
sound level.
RCA AUX-IN JACK
FM ANTENNA
