SERVICE PORT
2
Introduction
W arnings Specifications
Fine digital control
NTSC3.58
75W (Unbalance)
Model
Power adaptor
LCD
PLCD5092A-D
Display screen type Color active matrix LCD display
Sound output(Max) 2 x 10W
0 C-40 C o o
Display Size 50”
Power Consumption (Max) 250W
1920X1080
Display Screen Type
100-240V 50/60Hz
Remarks:
The above listed specifications and data are subject to change without prior notice.
Antenna: 2~69; Cable: 1~135 (Analog: 1-125,
Digital: 1-135)
