Maytag MMW7530WDS - Manuel (Page 8)

8
BROILING CHART
For best results, place food 3" (7 cm) or more from the broil
element. Times are guidelines only and may need to be adjusted
for individual tastes. Recommended rack positions are numbered
from the bottom (1) to the top (5). For diagram, see the
“Positioning Racks and Bakeware” section.
*Place up to 9 patties, equally spaced, on broiler grid.
Timed Cooking
Timed Cooking allows the oven to be set to turn on at a certain
time of day, cook for a set length of time, and/or shut off
automatically. DELAY TIME should not be used for food such as
breads and cakes because they may not bake properly.
Before setting, make sure the clock is set to the correct time of
day. See “Clock” section.
To Set a Timed Cook:
1. Press BAKE.
Press TEMPERATURE “plus” (+) or “minus” (-) keypad to set
a temperature other than 350°F (177°C) in 5° amounts. The
bake range can be set between 170°F and 500°F (77°C and
260°C).
2. Press COOK TIME.
3. Press HOUR and MINUTE “+” or “-” keypad until the desired
length of time appears on the display.
4. Press START. The start time, stop time and “TIMED” will
appear in the display.
The temperature and set cook time can be changed after this
step. Start does not need to be pressed again.
When the set cook time ends, the oven will shut off
automatically and “End” will appear on the display. End-of-
cycle tones will sound, then reminder tones will sound every
minute until Cancel is pressed.
5. Press LOWER CANCEL anytime to end Timed Cooking or to
stop reminder tones and clear the display.
To Set a Delayed Timed Cook:
1. Press BAKE.
Press TEMPERATURE “+” or “-” keypad to set a temperature
other than 350°F (177°C) in 5° amounts. The bake range can
be set between 170°F and 500°F (77°C and 260°C).
2. Press DELAY TIME.
3. Press HOUR and MINUTE “+” or “-” keypad until the desired
time of day to start appears on the display.
4. Press START. “DELAY” will appear in the display.
The temperature can be changed after this step. Start does
not need to be pressed again.
When the delay start time is reached, a tone will sound. The
display will count down the set cook time.
5. Press LOWER CANCEL when finished.
To Set a Timed Cook and Delayed Timed Cook:
1. Press BAKE.
Press TEMPERATURE “+” or “-” keypad to set a temperature
other than 350°F (177°C) in 5° amounts. The bake range can
be set between 170°F and 500°F (77°C and 260°C).
2. Press COOK TIME.
3. Press HOUR and MINUTE “+” or “-” keypad until the desired
length of time appears on the display.
4. Press DELAY TIME.
5. Press HOUR and MIN “+” or “-” keypad until the desired time
of day to start appears on the display.
6. Press START. “DELAY” and “TIMED” will appear in the
display.
The temperature and set cook time can be changed after this
step. Start does not need to be pressed again.
When the delay start time is reached, a tone will sound. The
display will count down the set cook time.
When the set cook time ends, the oven will shut off
automatically and “End” will appear on the display. End-of-
cycle tones will sound, then reminder tones will sound every
minute until Cancel is pressed.
7. Press LOWER CANCEL anytime to end Timed Cooking or to
stop reminder tones and clear the display.
FOOD
RACK
POSITION
Approximate Time
(minutes)
SIDE 1 SIDE 2
Steak
1" (2.5 cm) thick
medium rare
medium
well-done
4
4
4 14-15
15-16
18-19 7-8
8-9
9-10
Ground meat patties*
³ ₄" (2 cm) thick
well-done
4 13-14 7-8
Pork chops
1" (2.5 cm) thick
4 20-22 10-11
Ham slice, precooked
¹ ₂" (1.25 cm) thick
4 8-10 4-5
Frankfurters 4 5-7 3-4
Lamb chops
1" (2.5 cm) thick
4 14-17 8-9
Chicken
bone-in pieces
boneless breasts
3
4 17-20
11-16 17-20
11-16
Fish Fillets
¹ ₄-¹ ₂" (0.6-1.25 cm) thick
Fish Steaks
³ ₄-1" (2-2.5 cm) thick
4
4
8-10
16-18
4-5
8-9
WARNING
Food Poisoning Hazard
Do not let food sit in oven more than one hour before
or after cooking.
Doing so can result in food poisoning or sickness.
