5
LID LOCK INDICATOR
This light indicates that the lid is locked and
cannot be opened. If you need to open the lid,
press START/PAUSE. The lid will unlock once
the washer movement has stopped. This may
take several minutes if the load was spinning
at high speed. Press START/PAUSE again to
restart the cycle.
CYCLE STATUS LIGHT INDICATORS
The Cycle Status Lights show the progress of a cycle. At
each stage of the process, you may notice sounds or pauses
that are different from traditional washers.
FILL
When the Start/Pause button is pressed, the washer will
add a small amount of water to the load, then pause for
a few seconds. The lid will then lock and the washer will
continue to fill.
WASH
You will hear the motor and washplate moving the load.
It is normal for some of the load to be above the water
line. Low-water cleaning means concentrated cleaning.
Rather than diluting detergent as done in an agitator-style
washer, this washer delivers the detergent directly to the
soils. The motor sounds may change at different stages
in the cycle. The wash time is determined by the selected
Soil Level.
7
8
RINSE
You will hear sounds similar to the wash cycle as the washer
rinses and moves the load. You may hear the motor turning
on briefly to move the basket while filling. Fabric softener will
be added if the Fabric Softener option was selected. Some
cycles use spray rinsing.
SPIN
The washer spins the load at increasing speeds for proper
water removal, based on the selected cycle and spin speed.
DONE
Once the cycle is complete, this light will come on. Remove
the load promptly for best results.
ADD A GARMENT
You may place additional clothing in the wash when the
Add a Garment indicator is lit without sacrificing wash
performance. Press START/PAUSE once. The Lid Lock light
will turn off. Open the washer lid, add garments and close
the lid. Press START/PAUSE to restart.
CLEAN WASHER REMINDER
The Clean Washer Reminder indicator lights after 30 wash
cycles without a clean washer cycle. See the “Washer Care”
section to run the clean washer cycle, or you can press
REMINDER RESET button to manually reset clean washer
cycle counter.
Dispensers
High Efficiency “HE” detergent dispenser
Add liquid or powdered HE detergent product
to this dispenser for your main wash cycle.
Liquid chlorine bleach dispenser
This dispenser holds up to 3/4 cup (180 mL) liquid
chlorine bleach. The bleach will be automatically
diluted and dispensed at the optimum time during
the wash cycle. This dispenser cannot dilute
powdered bleach. Use the liquid chlorine bleach
dispenser for liquid chlorine bleach or color-safe bleach.
Liquid fabric softener dispenser
Pour measured liquid fabric softener into
the liquid fabric softener dispenser, if desired.
It will dispense automatically at the optimum
time when the Fabric Softener option is selected.
• Use only liquid fabric softener in this dispenser.
• Do not overfill. Do not dilute. The dispenser holds 3 oz
(94 mL), or a capful of fabric softener.
• Fabric softener is dispensed in a deep rinse when
the Fabric Softener option is selected. If Extra Rinse is
selected, the fabric softener will be dispensed during
the final rinse.
A
B
Use only High Efficiency (HE) detergent.
C
A
C
B
• Do not use fabric softener dispensing balls in this washer.
Dispensing balls will not operate correctly with this washer.
• Do not spill or drip any fabric softener onto the clothes.
• At the end of the cycle, a small amount of water may be left
in the dispenser. This is normal.
