Maytag MGD8100DC - Manuel (Page 6)

6
CONTROL PANEL AND FEATURES
Not all features and cycles are available on all models.
NOTE: The control panel features a sensitive surface that responds
to a light touch of your finger. To ensure your selections are registered,
touch the control panel with your finger tip, not your fingernail. When
selecting a setting or option, simply touch its name.
POWER/CANCEL
Touch to turn the dryer on and off. Touch to stop/cancel
a cycle at any time.
CYCLE CONTROL KNOB
Turn the knob to select a cycle for your laundry load. Sensor
Cycles are Power Dry, Normal, Delicates, Sanitize (on some
models), Bedding (on some models), and Wrinkle Control
(on some models). Timed Cycles are Timed Dry and Rapid
Dry. The Steam Cycle (on some models) is Refresh. See
“Cycle Guide” for detailed descriptions of cycles.
START/PAUSE
Touch and hold until the LED comes on to start a cycle,
or touch once while a cycle is in process to pause it.
LED DISPLAY AND SETTINGS
When you select a cycle, its settings will light up and the
Estimated Cycle Time (for Sensor Cycles) or actual time
remaining (for Timed Cycles) will be displayed. On 2-digit
displays, for times longer than 99 minutes, hours will be
displayed followed by minutes.
See “Cycle Guide” for available settings on each cycle.
Not all settings are available with all cycles.
–/+ (Timed Dry Adjust)
Touch “+” or “–” with Timed Cycles to increase
or decrease the length of a Timed Dry or Rapid
Dry cycle.
Temperature
When using Timed Cycles or Refresh, you may select
a dry temperature based on the type of load you are
drying. Use the warmest setting safe for the garments
in the load. Follow garment label instructions.
NOTE: Sensor Cycles use a preset temperature that
is not adjustable.
Dryness Level
When using Sensor Cycles (except for the Sanitize
cycle), you may select a Dryness Level based on the
type of load you are drying.
NOTE: Dryness Level is for use with Sensor Cycles only.
1
2
3
4
3
2
1
4
5 6
Wrinkle Prevent
If you will be unable to remove a load immediately, touch
Wrinkle Prevent to add up to 140 minutes of periodic
tumbling to help reduce wrinkling. On some cycles, you
may select the “With Steam” setting to add a short steam
cycle after 60 minutes to help smooth out wrinkles.
Energy Saver
Touch to activate the Energy Saver option, which allows
you to increase your energy savings by using a slightly
lower heat level. Energy Saver will increase drying times
by approximately 40 minutes; the LED Display will reflect
this time.
Energy Saver is only available for Normal. For optimal
energy, turn on the Energy Saver option. For optimal time,
turn off the Energy Saver option.
NOTE: Energy savings may vary across loads.
OPTIONS
Use to select available options for your dryer. Not all cycles
and options are available on all models.
My Cycle
If you have a favorite cycle with custom settings that you
use frequently, you can use the My Cycle feature to keep
your preferred settings ready to use. To save the cycle
press and hold MY CYCLE (approximately 3 seconds)
until a beep sounds and the letters “SET” are displayed on
your machine. When selecting My Cycle refer to the LCD
display for additional options and settings.
Drum Light
Touch to turn the LED drum light on or off. The light
will also turn on when the door is open, and turn off
automatically after about 5 minutes.
Reduce Static
Touch to add the Reduce Static option to selected
Sensor cycles (see “Cycle Guide”). The dryer will
automatically tumble, pause, and introduce a small amount
of moisture into the load to help reduce static. This option
adds approximately 8 minutes to the total cycle time.
5
