4
Parasource Active
Speaker Features
• PS10P: Integrated 1600 Watt Amplifier
(1600W Peak/800W Program)
• PS12P & PS15P: Integrated 4400 Watt
Amplifier (4400W Peak/1400W Program)
• PS10P: 10-inch Woofer with 2-inch Voicecoil
• PS12P: 12-inch Woofer with 3-inch Voicecoil
• PS15P: 15-inch Woofer with 3-inch Voicecoil
• 38mm Compression Driver / 1-inch Exit with
Thermal and Peak Protection
• PS10P: 90° x 70° Horn
• PS12P & PS15P: 85° x 50° Horn
• PS10P: Max SPL 127dB Peak (124dB Continuous)
• PS12P: Max SPL 133dB Peak (128dB Continuous)
• PS15P: Max SPL 134dB Peak (129dB Continuous)
• High Efficiency Bi-Amplified Class-D Power Module
• Passive Cooling Scheme (No Loud Fans Required)
• Designed for Front-of-House or Monitor Applications
• Integrated Two Channel Mini Mixer with XLR Microphone,
1/4-inch and RCA Line Inputs
• Multiband Limiting Delivers Extremely Transparent Listening
Experience (Vocals Are Not Modulated By Bass)
• Ergonomic All Metal Handles
• Integrated All Metal Speaker Standmount Adaptor
• Integrated Reinforced Flypoints
• Lightweight ABS Cabinet Construction
•
Made in Canada
