13
PS10P PS12P PS15P
System Type Active Loudspeaker Active Loudspeaker Active Loudspeaker
Active or Passive Active Active Active
Program Power (watts) 800 watts (1600 watts peak) 1400 watts (4400 watts peak) 1400 watts (4400 watts peak)
Max SPL (dB) 127dB Peak (124dB Continuous) 133dB Peak (128dB Continuous) 134dB Peak (129dB Continuous)
Frequency Response (Hz +/- 3dB) 55hz to 20kHz 45Hz to 26kHz 45Hz to 26kHz
Crossover Frequency (Hz) 1.3k 1.3k 1.1k
Driver Configuration 10-inch / 1-inch 12-inch / 1-inch 15-inch / 1-inch
HF Driver(s) 38mm Voicecoil w/ 1-inch Exit 38mm Voicecoil w/ 1-inch Exit 38mm Voicecoil w/ 1-inch Exit
HF Dispersion (°H x °V) 90 x 70 85 x 50 85 x 50
HF Protection Thermal/Peak Limiter Thermal/Peak Limiter Thermal/Peak Limiter
LF Driver(s) 10-inch Ceramic w/ 2-inch Voicecoil 12-inch (3 inch voicecoil) 15-inch (3 inch voicecoil)
LF Protection Thermal/Multiband Peak Limiter Thermal/Multiband Peak Limiter Thermal/Multiband Peak Limiter
LF Processing Dynamic Bass Extension Dynamic Bass Extension Dynamic Bass Extension
Cooling Scheme Passive Passive Passive
Power Cable Detachable IEC Detachable IEC Detachable IEC
Power Consumption (typ/max) MAX: 1.25 A @ 120 Vac / 0.6 A @ 230 Vac MAX: 1.6 A @ 120 Vac 0.8 A @ 230 Vac MAX: 2.0 A @ 120 Vac 1.0 A @ 230 Vac
Inputs 1/4-inch, XLR, RCA 1/4-inch, XLR, RCA 1/4-inch, XLR, RCA
Inputs - 1/4-inch Jacks Yes (x2) Yes (x2) Yes (x2)
Inputs - XLR Yes (x2) Yes (x2) Yes (x2)
Input Sensitivity (Vrms Sine) 1.23 Vrms +4dBu 1.23 Vrms +4dBu 1.23 Vrms +4dBu
Mixer Controls Sub Mode HPF, Bass Boost, Mixer Enable Sub Mode HPF, Bass Boost, Mixer Enable Sub Mode HPF, Bass Boost, Mixer Enable
Level Controls Master Level, Mic Level, Line Level Master Level, Mic Level, Line Level Master Level, Mic Level, Line Level
LED Indicators Power, Limit, Clip Power, Limit, Clip Power, Limit, Clip
Bar Handles Yes Yes Yes
Pole Mount Adapter (1 3/8-inch-3.5cm) Yes Yes Yes
Enclosure Materials ABS ABS ABS
Baffle Material ABS ABS ABS
Grille Perforated Metal Perforated Metal Perforated Metal
Dimensions (DWH xbackW COM inches) 23 x 14 x 12 26.25 x 16.75 x 13.5 30.75 x 20.5 x 14.5
Dimensions (DWH xbackW COM cm) 58.4 x 35.6 x 30.5 66.7 x 42.5 x 34.3 78.1 x 52.1 x 36.3
Weight (lbs/kg) 40/18.2 40/18.2 60/27.8
Specifications
=
