Curtis RPW091 - Manuel (Page 7)

The wash stops
Program selection
1 Install the washing
machine
3 Measure out the
detergent
7 Plug the power supply
6 Turn on the water tap
8 Select the desired
program
5 hang up
the drain pipe
4 Close the top lid
9 Press the
[start/pause] key
10
When the wash stops, the buzzer will buzz continuously for 6 times and
then the power will be automatically cut off.
Turn off the water tap .
Although the power can be cut off automatically, the power plug must be pull
out as well for the safety.
1 Press the button. “ON/OFF”
3 To press the “start/pause” key.
2 Select the proper water level or other attached functions .
2 Load the laundry
Instruction to the program Heavy
Instruction to single wash procedure
Instruction to self-programmed procedure
Steps in details
1.Press the switch.
2.According to the washing amount choose the proper water level.
3.Press “START/PAUSE” button.
“ON/OFF”
11
! Close the lid of the door when machine is running, otherwise, it will automatically
stop working during spin process and send out abnormal warning.
! The washer will not work when the filled water does not reach the set water level.
! [Heavyl] wash program is the easiest, most convenient and most common washing
program. When the user press the power switch and then press [Start/Pause] button,
the
washing program will start to work.
! When the washer start to work, the digital tube show the remain time. The indicator
light which stand for remaining time is flickering.
Heavy
! User may freely select any single procedure, or any combination of procedures
among WASH, RINSE and SPIN according to the actual requirements. It is only
required to turn off any one or two of these three indicators that not needed by the
user. And keep the indicator be on showing the process needed by the user.
! Single wash -- after switching on the power, turn off RINSE and SPIN two indicators
by pressing these two keys. The operation for single rinse and single spin is similar.
! Single wash-spin – after switching on the power, turn off RINSE indicator by pressing
that key. The operation for single rinse-spin and single wash-rinse is similar.
! User can freely select any combination among WASH, RINSE and SPIN modes
according to the dirty degree of clothes.
Detail operation methods are following:
Continuously pressing the washing button to select washing time.
(1~20 minutes, or no wash process)
Continuously pressing the rinse button to select rinse times.
(1~3 times, or no rinse process)
Continuously pressing the spin button to select the spin time.
(3~9 minutes or no spin process)
NOTICE
！
Quick start The main wash
