7
Parts identification of the washer
Upper drain hose
(for upper drain only)
Power line
Impeller
Cabinet
Adjustable foot knob
Handle
Control panel
Water inlet valve
Door
Wash Spin barrel
Warning lable
Washing powder box
6
Before washing, please do take out coins,
keys and other hard goods, and pull to close
the zip fastener to prevent clothes and
barrel from damage.
Preparation before washing
！
NOTICE
Adjust the adjustable foot making
the washer be placed stable. 1
Adjustable foot (extend when
clockwise rotating and shorten
when counterclockwise rotating)
(Slightly incline the washer first and loosen the
adjustable foot knob. Adjust the adjustable foot so
as to ensure four corners of washer be steadily
contacted with the ground. Then tighten the
adjustable foot knob and lock it. If the ground is
obviously not flat, correction should be made on
the ground surface, otherwise the washer barrel
will incline and knock the cabinet)
Install the water
inlet hose. 2
Connect with
power source. 3
4 Open the
water tap.
+ +
Put down the drain
hose. 5
Upper drain
Note:
The water
will overflow
when the
height of
the drain
hose under
860mm.
>
860mm
Put in
clothes
and
suitable
amount of
washing
powder. 6
+ +
Note: Water temperature
should not be higher than
30 degree.
Accessories
Water inlet hose assembly Base cover
Self-tapping screw
Only for models including base cover Only for model with double
screw thread water inlet pipe
Please refer to the real material as the attachment
