8
LISTEN TO EXTERNAL AUdIO dEvICE
This unit provides with an auxiliary input jack to connect your cell phone or MP3
player, etc.
1.) Use an audio cable (not included) with 3.5mm stereo plug on each end of the
cable.
2.) Plug one end into the AUX IN Jack on the rear of the unit and the other end of
the cable into the Line-out jack or phone jack on your external audio device.
3.) Press the POWER FUNCTION button repeatedly until “AU” appears on the
display, the unit will turn to AUX IN mode.
4.) Activate your external device.
5.) During playback:
Press the VOLUME+/ AL1 button to increase the volume.
Press the VOLUME-/ AL2 button to decrease the volume.
NOTE:
i. / or buttons only work with a Bluetooth source.
ii. If there is no sound, or the sound is not loud enough, you can increase the
volume from your source device.
iii. There is a USB port on the rear of the unit to charge an iPod/iPhone
device.
BLUETOOTH OPERATIONS
PAIRING
1. Press the POWER/FUNCTION button repeatedly until “bt” appears on the
display.
2. Activate the Bluetooth pairing on your external device. The source will now scan
for other Bluetooth devices and should find the unit, identified as
Choose it to pair with your device.
3. Press the button to start playback.
NOTE:
i. Enter 0000 if asked for a password during pairing.
ii. Before pairing, disconnect the AUX IN cable.
PLAYBACk CONTROL
Press
to skip to the previous track.
Press to skip to the next track.
Press to switch between play and pause.
Press VOLUME+/ ALARM1 button to increase the volume.
Press VOLUME-/ ALARM2 button to decrease the volume.
SCR1997
